1.5.
Installing the SMARC
The MXM3.0 connector on RP-103-SMC supports the SMARC form factor
(82mm x 50mm).
To install SMARC modules to the MXM slot on the board, please
perform the following steps:
-
Hold the SMARC module so that the edge fingers of the SMARC
module aligns with the MXM connector.
-
Gently push the SMARC module to the MXM connector until the
edge fingers of SMARC completely touch the bottom of the slot.
-
Gently press the SMARC module down and fix it with four screws.
RP-103-SMC User Manual
1
Introduction
11
