SW3: I/O & Display
I/O Output Select
SW3_1-8
ON CN31 I/O Free Definition
OFF CN31 I/O Normal Function (Default)
DSI0 Output Select
SW3
2-7 3-6
ON ON
ON OFF
OFF x
DSI1 Output Select
SW3_4-5
ON
OFF
62
Select
Function
Function
DSI0 Output
LVDS2 Output
LVDS0 CH0 Output
Function
HDMI TX2 Output
DSI1 Output
