2.4. Connectors on RP-103-SMC

P1 DC-in
P2 Internal DC-in
P3 SD/MMC slot
P4 SD/MMC slot (2.2.1
P5 HDMI TX1/EDP TX
P6 HDMI TX2 (2.2.1
P7 HDMI RX (2.2.1
)
P8 LAN0
P9 LAN1 (2.2.1
)
P10 mPCIe slot
P11 SIM slot
P12 M.2 E-Key 2230 slot
P13 USB1/2
P14 MXM3 slot
P15 DSI0/LVDS2 Backlight power select CN15 LVDS1 ch1
P16 DSI0/LVDS2 LCD power select
P17 DSI1 Backlight power select
P18 DSI1 LCD power select
P19 LVDS0 Backlight power select
P20 LVDS0 LCD power select
P21 LVDS1 Backlight power select
P22 LVDS1 LCD power select
P23 Headphone & Mic.
P24 Line In/Out
P25 OTG USB
P26 RS232/422/485
SW1 Boot Mode Select
SW2 UART Mode Select
SW3 I/O & Display Select
SW4 Power ON/OFF button
SW5 Sleep button
SW6 LID button
SW7 Reset button
Note:
(2.2.1): RM-N8 module use only
RP-103-SMC User Manual
)
)
(2.2.1
)
(2.2.1
)
(2.2.1
)
(2.2.1
)
Settings on the Carrier Board
CN1 QSPI
CN2 SPI (2.2.1
)
(2.2.1
CN3 SPI
)
CN4 MIPI DSI0
CN5 LVDS2 ch0
CN6 LVDS2 ch1
CN7 DSI0/LVDS2 Backlight
CN8 DSI0/LVDS2 TP (i2c for touch)
CN9 MIPI DSI1 (2.2.1
)
CN10 DSI1 Backlight
CN11 LVDS0 ch0
CN12 LVDS0 ch1
CN13 LVDS0 Backlight
(2.2.1
CN14 LVDS1 ch0
(2.2.1
CN16 LVDS1 Backlight
CN17 LVDS1 TP (i2c for touch)
CN18 Speaker L
CN19 Speaker R
CN20 USB3/4
CN21 MIPI CSI1 (2.2.1
)
CN22 MIPI CSI2
CN23 SATA0 (2.2.1
)
CN24 SATA power (2.2.1
CN25 SATA1
CN26 SATA power
(2.2.1
CN27 CAN0/1
)
CN28 CAN2/3
CN29 COM1/3
(2.2.1
CN30 UART0/4
)
CN31 DIO
CN32 FAN
CN33 UART(4-wire)
CN34 BTB Conn (2.2.1
)
CN35 RTC BAT
(2.2.1
)
)
)
(2.2.1
)
(2.2.1
)
)
