2.2.2 Events
Events are defined by the following inputs and reader states:
•
•
•
•
•
•
•
•
•
•
2.2.3 Actions
An action is defined by the type of action that occurs for a specific event and
consists of the following:
•
•
•
•
2.2.4 Panels
Correlations can be applied to either one of the panels on your system, all of the
panels on your system, to a custom group of panels on your system (for TCP/IP
networks only), and across all panels on the network. They can occur on the local
panel, distributed panels or different types of panels (Card Access and Telephone
Access) on the network.
Note:
2.2.5 Output
Actions are applied to an output on the panel(s) selected. This option specifies
which output.
TX3-CX Card Access System Installation and Operation Manual
Version 4.1
LT-980 Copyright 2017
Access is granted (from Reader A or B)
Access is denied (from Reader A or B)
Forced entry alarm (from Reader A or B)
Door held open alarm (from Reader A or B)
Door not open (from Reader A or B)
Input is active (from Inputs 1 to 8)
Unlock mode is on (from Reader A or B)
Unlock mode is off (from Reader A or B)
High security is on (from Reader A or B)
High security is off (from Reader A or B)
Turn ON output
Turn OFF output
Turn ON high security
Turn OFF high security
Correlation signals cannot be transmitted by Touch Screen Master
Nodes. If you plan on setting up correlations either all of the panels
on your network or a custom group of panels, consult LT-995 for
instructions on selecting the Route IP Correlations checkbox.
Configurable Features
