B.3 Connectors
B.3.1 LAN Connector

LAN Connector

RJ45 LAN
B.3.2 WAN Connector

WAN Connector

RJ45 WAN
B.3.3 WWAN/Cell Connector (female)
WWAN/Cell Connector
Teldat Router Connect-104V
RJ45 PINOUT
1
2
3
4
5
6
7
8
RJ45 PINOUT
1
2
3
4
5
6
7
8
PINOUT
Internal
External
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
ANT
RF in/out
GND
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
