Teldat S.A.
A.3 Connectors
A.3.1 LAN (FE x) Connector
RJ45 LAN
A.3.2 BRI Connector
RJ45 ISDN
A.3.3 ANT Connectors
ATLAS 50
RJ45 PIN
1
2
3
4
5
6
7
8
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
LAN
Tx+(input)
Tx-(input)
Rx+(output)
--
--
Rx-(output)
--
--
ISDN
--
--
Tx+(output)
Rx+(input)
Rx-(input)
Tx-(output)
--
--
ANT
RF in/out
GND
Technical Information
13
