Teldat S.A.
B.4.9 Power Supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
B.4.10 External Power Supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
B.4.11 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
B.4.12 Environmental Specifications
TEMPERATURE
RELATIVE HUMIDITY
Teldat Router Connect-104V
+12V DC.
1200 mA
5.5 mm
2.5 mm
100-240V AC
1.0 A
50-60 Hz
Desktop.
242 x 179 x 48 mm.
0.8 Kg.
OPERATING NORMALLY: 0ºC to 40ºC
STORED: -30ºC to 85ºC
On: 5% to 90%
Appendix
23
