PFC-OMND
Installation Guide
5
INSTALL THE CABLE MANGEMENT COVERS
1. Cut the vinyl covers to size if applicable.
2. Make a cutout for the power cable.
3. The endcaps are removable for ease of installation.
4. Slide in or pinch and push the vinyl covers into the raceway.
Cutout for
the power
cable
M4 x 10mm Pan
Vinyl covers
Head Screw
PUSH
Endcap
Pinch and push
into the raceway
THE MOUNT IS READY.
www.premiermounts.com | North America 800.368.9700 | International +1-714-632-7100
Page 9
