Summary of Contents for Premier Mounts PTM
- Page 1 INSTALLATION INSTRUCTIONS PTM / PTM-B Tilt/Pivot Mount HEADQUARTERS 1321 S. State College Blvd. Fullerton, CA 92831 USA USA and Canada Phone: 1.800.368.9700 Fax: 1.800.832.4888 Other Locations Phone: (001).714.632.7100 Fax: (001).714.632.1044 9531-018-011-0X Rev. 5...
-
Page 2: Table Of Contents
SAFETY EQUIPMENT AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY. PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY... -
Page 3: Installation Tools
LES SUPPORTS PREMIER MOUNTS NE GARANTISSENT PAS CONTRE LES DOMMAGES CAUSÉS PAR L’USAGE DU PRODUIT DE MONTAGE PREMIER MOUNTS À D’AUTRES FINS QUE CELLES POUR LESQUELLES IL A ÉTÉ CONÇU OU DES DOMMAGES CAUSÉS PAR DES ACCESSOIRES OU DES MODIFICATIONS NON AUTORISÉS, ET NOUS NE POUVONS PAS ÊTRE TENUS RESPONSABLES DES DOMMAGES, PLAINTES, RÉCLAMATIONS, POURSUITES, ACTIONS OU CAUSES D’ACTION DE N’IMPORTE QUELLE MANIÈRE... -
Page 4: Parts List
Features Parts List Your Premier Mounts product is shipped with all proper installation hardware and components. Make sure that none of these parts are missing and/or damaged before beginning installation. If there are parts missing and/or damaged, please stop the installation and contact Premier Mounts (800) 368-9700. -
Page 5: Installing The Wall Plate
Determining the Mounting Surface If you will be installing your PTM mount to wood studs, proceed to the “Wood Stud Installation” section. If you will be installing your PTM mount to a concrete wall, proceed to the “Concrete Installation” section. -
Page 6: Concrete Installation
Concrete Wedge Anchors You will need a ″ concrete drill bit, which is available at your closest hardware store. ″ Example of Concrete Drill Bit (Not Included) Page 6 Installation Instructions Visit the Premier Mounts website at http://www.mounts.com... - Page 7 Insert a concrete wedge anchor into each hole. If necessary, lightly tap each concrete wedge anchor into place with a hammer. Remove the nuts and washers from all four (4) concrete wedge anchors. Installation Instructions Page 7 Visit the Premier Mounts website at http://www.mounts.com...
-
Page 8: Mounting Hardware
« Installation d’entretoise tous usages ». Si Non, aller directement à la section If No, skip to the “UFP-280 Adapter Plate Installation” section. « Installation de la plaque d’adaptateur UFP-280 ». Page 8 Installation Instructions Visit the Premier Mounts website at http://www.mounts.com... -
Page 9: Universal Spacer Installation
Mounting Hardware (cont’d) Universal Spacer Installation Premier Mounts’ Universal Spacers allow you to attach the mounting bracket to flat panels which have recessed or uneven mounting points. Each Universal Spacer adds ¼˝ to the distance between the Adapter Plate and your flat panel. -
Page 10: Attaching The Flat Panel To The Mount
Flat Panel with UFP-280 Adapter Plate Attaching the Mount to the Wall Plate Your PTM mount must be attached to the back plate that is secured to the wall. The back of your PTM PTM Mount mount has a built-in bracket designed to “hang” on the wall plate. -
Page 11: Securing The Mount
Tension Nut Replacing the Mount Replace PTM mount by guiding the heads of the top two (2) M4 x 5mm Phillips screws through the keyhole slots. Insert two (2) M4 x 5mm Phillips screws into the bottom mounting points. Tighten all M4 x 5mm Phillips screws. -
Page 12: Technical Specifications
C: 200mm x 100mm mounting points. (M4 x 10mm Phillips flat head screws only) D: 200mm x 200mm mounting points. (If M4 screws are used, M5 washers must be used as well) Page 12 Installation Instructions Visit the Premier Mounts website at http://www.mounts.com... -
Page 13: Warranty
The information contained in this document is subject to change without notice or obligation of any kind. Premier Mounts makes no representation of warranty, expressed or implied, regarding the information contained herein.
