3
1. Remove the handles (if attached on the OMN-D) before proceeding.
2. Carefully transport the flat-panel display to the mount and fasten using
M8 x 35mm Button Hex screws where applicable. A minimum of 4
mounting points (2 per side) must be use to safety secure the display.
minimum of 2
mounting points
per side
Shown using OMN55-D for visual clarity. Mounting location will vary based on the viewing height.
INSTALLING THE OMN-D TO THE MOUNT
Ceiling Installation
Manually operated
material lift
(Recommended)
www.premiermounts.com | North America 800.368.9700 | International +1-714-632-7100
PFC-OMND
Installation Guide
Floor Installation
minimum of 2
mounting points
per side
2 Person
Recommended
M5 X 35
Button Hex
Page 7
