Premier Mounts PFC-OMND Installation Manual page 5

C
APPLICATIONS:
• FLOOR TO CEILING (USES X2 PFC-OMND).
If power and data are
routed from the ceiling,
adjustable viewing height
by installing at varies
mounting location. See
table on page 3.
Section Line (center)
78-7/8" [2004.2]
If power and data are
routed from the floor, the
viewing height is mounted
at a fixed location and can
only be adjusted by cutting
the bar. See page 4.
Table shown aboved measured from bottom of
the base.
Subtract 1/4" [6.35] if using the dimension to cut
[actual length 78.65" [1997.7] long bar.
DETERMINE THE VIEWING HEIGHT
www.premiermounts.com | North America 800.368.9700 | International +1-714-632-7100
PFC-OMND
Installation Guide
Cutting only to fit
between the floor
and ceiling.
157-7/8" [4008.4]
Max Height
1/4"
[6.35]
Page 5
