Generic installation instructions

Elite Classic

Using these instructions

These instruction are provided primarily to demonstrate how to install HydroTap
sufficient information to install and commission complete HydroTap
installation requirements detailed in the installation instructions provided with the Command-Centre
any change to the complete system.

Min / Max water supply pressure requirements

HydroTap s and Mains All-in-One taps sparkling models..................0.25 MPa (2.5 bar) - 0.7 MPa (7 bar)
®
HydroTap s and Mains All-in-One taps non-sparkling models...........0.17 MPa (1.7 bar) - 0.7 MPa (7 bar)
®
Vented All-in-One sparkling models....................................................0.25 MPa (2.5 bar) - 0.7 MPa (7 bar)
Mixer taps and Vented All-in-One non-sparkling model taps..............0.20 MPa (2.0 bar) - 0.7 MPa (7 bar)
Tap installation special tool requirements
In addition to normal tools, the following will be required.
For the HydroTap G4, Celsius and mixer taps.
®
• 35mm diameter sheet metal hole punch for sinks (not supplied).
• 35mm diameter hole saw for worktops (not supplied).
• Nut runner tube spanner (supplied for all but Celsius & mixer taps) for fixing the tap assembly.
For the All-in-One tap.
• 50mm diameter sheet metal hole punch for sinks (not supplied).
• 50mm diameter hole saw for worktops (not supplied).
• Nut runner tube spanner (supplied) for fixing tap assembly.
Font installation special tool requirements
• Sheet metal punch or hole saw to suit surface being cut. Ø140m for Arc / Cube and Ø108mm for
Classic and Elite.
Page 4 of 20
Arc / Cube
All-in-One
HydroTap s
®
Celsius Classic
G4 systems. Please refer to all safety and
®
803341UK G4 Tap installation instructions v1.02 June 2016
