- Page 1 Zip HydroTap G4 ® Installation and Operating Instructions Chilled Commercial Affix Model Number Label Here 801525 801525 v3.05 09.20 HT C Com Install Instructions Page 1 of 16...
-
Page 2: Step
Tap options The Zip HydroTap G4 appliance series offers a range of interchangeable taps to suit the customer’s needs Classic Tap These three taps are directly compatible with the G4 Command Centre. Arc / Cube Tap Elite Tap Page 2 of 16... -
Page 3: Table Of Contents
Index HydroTap Specifications Installation Checklist ........................4 General Product Features ......................5 Important Safety Instructions ....................... 6 Warnings and Regulatory Information ..................7 Major Components and Accessories ................... 8 Technical Specification ........................ 8 Before Installation and Site Requirements ................... 9 Installation Instructions STEP 1 - Measure and cut all the tap holes before fitting the taps... -
Page 4: Installation Checklist
Installation checklist Before Installation: Read the instructions and check if there is adequate space to mount all of the components. Note: Not all fittings are supplied with the appliance kit. Isolation valves are not supplied. Check the mains water pressure is between 150 - 700kPa Check the water quality to determine if extra filtration will be required. -
Page 5: General Product Features
General Product Features Thank you for purchasing a Zip Chilled HydroTap. Please read and follow these instructions carefully to ensure safe operation and trouble free service. If service is required, please call your Zip Service Provider. What is the Zip HydroTap ? The Chilled Zip HydroTaps are electronically controlled to supply filtered and Chilled drinking water for kitchens and tea rooms. -
Page 6: Important Safety Instructions
Lifting Take care when lifting the Zip HydroTap unit. Some units may exceed safe lifting limits. If you feel this is beyond your personal capabilities, please seek assistance with the lift. The weights of the units are marked on the packaging. -
Page 7: Warnings And Regulatory Information
WARNINGS WARNINGS 1. The Zip HydroTap unit must be earthed. The resistance of the earth connection from each exposed metal part must be less than 1 ohm. 2. All Installation and service work must be completed by trained and suitably qualified Tradespeople. -
Page 8: Major Components And Accessories
Major Components and Accessories Parts supplied Description Accessories Description HydroTap Font Kit for with hoses Arc & Cube Models (Classic tap shown) 1 off Font Kit for Classic & HydroTap Elite Models Command Centre with water filter 1 off Mains water connection hose Replacement Filter Vent Kit... -
Page 9: Before Installation And Site Requirements
Before Installation and Site Requirements Before installing ensure that the following have been provided at the installation site: • Review all the technical specifications. • Ensure the underbench can support the product weight when full of water, (allow an extra 3 kg when full. ) •... -
Page 10: Section 2 - Ventilation
Section 2 Ventilation When installing air flow ducts, the following tools will be required: • Jigsaw and 12mm drill. • Keyhole or Wall Board saw. Recommended Installation showing the correct air flow MIN. 50mm Cool Air IN via cabinet floor, **MIN. - Page 11 Ventilation Min. 35mm NOTE: The following instructions are critical if the cupboard temperature rises above 35°C or the vent kit, as supplied, is not fitted: Additional ventilation is required. Options include the HydroTap vent tray kit or auxiliary fan kit. Contact your local service centre for availability.
-
Page 12: Section 3 - Command Centre Installation
Section 3 Command Centre Installation 90° Bend end Hose and tube fitting of Braided Hose Braided hose for • Remove all caps from the top of the Command Mains Water Supply Centre • Fit the foam insulation to the Blue tube after Connector + Strainer trimming to length. -
Page 13: Section 4 - Commissioning
Section 4 Commissioning Do not commission your HydroTap until it is ready to be used! The HydroTap is designed to be installed, commissioned and used within 48 hours. If your HydroTap is left idle before use, a filter change and sanitisation may be required. -
Page 14: Command Centre Flush
Commissioning 1. Turn the stop cock ON 2. Press [Start] [Stop] buttons to start and stop the filter flush. 3. Allow at least 10 litres of water to flush through the filter. 4. Once the filter flush is finished, Turn the stop cock OFF then press [Stop] to end filter flush mode. -
Page 15: Troubleshooting
Internal fault Call Zip Service Call an electrician, a plumber, or Zip service provider for assistance, service, spare parts or enquiries. End of Life Disposal In order to help preserve our environment we ask that you dispose of this product correctly. Please contact your local city council for collection centre details. -
Page 16: Contact Details
Zip Water (Aust) Pty Ltd ABN 46 000 578 727 67-77 Allingham St, Condell Park NSW 2200 Postal: Locked Bag 80, Bankstown 1885 Australia zipwater.com | (+612) 9796 3100 | 1800 ZIP TAP (1800 947 827) WMKA21821 WMTS-105 The terms “Zip” and “HydroTap” are registered trade marks of Zip Water (Aust) Pty Ltd.
