CHAPTER 4: COMMUNICATION
Input
Data
Register
Size
Address
100
32 bit
101
4.31
Parameter Name
EntelliPro ES Status
bit0 - Contactor1FeedbackStatus
bit1 - Contactor2FeedbackStatus
bit2 – ParameterModeStatus
bit3 - SwitchProtectedStatus /
BlockLocalSwitchON
bit4 – StartAttempt
bit5 – DrawerReadyStatus
bit6 – GeneralWarningStatus
bit7 – GeneralFaultStatus
bit8 - Safety circuitStatus
bit9 - ESS_DPLocalModeStatus
bit10 - ESS_DPRemoteModeStatus
bit11 - DrawerOperationMode Status
bit12 - DrawerTestModeStatus
bit13 - LimitSwitch1Status
bit14 - LimitSwitch2Status
bit15 – GeneralDeviceErrorStatus
bit16 – Feedback_IdentificationStatus
bit17 - Class1Failure
bit18 - ModbusFailure
bit19 - ByPassSwitchedON
bit20 - Switching1Progress
bit21 - Switching2Progress
bit22 - BreakerTripped2
bit23 -StatusCharged
bit24 - TorqueSwitching1Progress
bit25 - TorqueSwitching2Progress
bit26 -StartPhase
bit27 -RunPhase
bit28 - ThermistorLineBroken
bit29 -Thermistor Line Shorted
Units
Scale
Format
Unsigned Integer
EP OS MOTOR MANAGEMENT SY STEM – INSTRUCTION MANUAL
Note
Status Definition
When Relay 41 is turned ON , on receiving the feedback signal
from of the the mapped input, the status will be set to 1
When Relay 43 is turned ON , on receiving the feedback signal
from of the the mapped input, the status will be set to 1
When an OFF command is received by the Remote source,
and the switch control is set to local, and the block local
switch ON is actiavted, the status will be set to 1
When the Start attempts exceeds the parmeterized
counter,the status will be set
When there is no fault or device error, the local-remote-off
switch position is set, drawer mode is selected and no OFF
command is issued, status will be set to 1
When any warning exist, the status will be set to 1
When any fault exist, the status will be set to 1
When there is safety circuit digital input, this bit would be
set to 1
When the local-remote-off switch is set to local, the status will
be set to 1 source
When the local-remote-off switch is set to remote, the status
will be set to 1 source
When drawer is in operation mode, the status will be set to 1
When drawer is in test mode, the status will be set to 1
When limit switch1 digital input is present, the status will be
set to 1
When limit switch2 digital input is present, the status will be
set to 1
When any of device error exist, the status will be set to 1
When command is received to identify the EntelliPro ES, the
status will be set to 1
When there is a Profibus Class1 failure, the status will be
set to 1
When there is a Modbus failure, the status will be set to 1
Typical Specific-- Need to have corresponding digital input
When relay 41 is ON and no feedback is yet received, the
status will be set to 1
When relay 43 is ON and no feedback is yet received, the
status will be set to 1
Typical Specific-- Need to have corresponding digital input
Typical Specific-- Need to have corresponding digital input
Typical Specific-- Need to have corresponding digital input
Typical Specific-- Need to have corresponding digital input
When the motor is in the start phase, the status will be set
to 1
When the motor is in the run phase, the status will be set to 1
When there is thermistor open failure, the status will be set
to 1
When there is thermistor short failure, the status will be set
to 1
