Service Manual
H1P 045/053/060/068 Axial Piston Single Pumps
Torque Chart
B020 O-ring plug, 1-1/16 - 12
D250
Electric control
mounting bolt
D015 Neutral adjusting screw
D060 Neutral adjust locking nut
D050 Coil mounting bolt
E350
Servo cylinder locking bolt
B020 O-ring plug, 1-1/16 - 12
©
Danfoss | June 2020
M14 O-ring plug, 7/16 - 20
B015 O-ring plug, 7/16 - 20
G251 O-ring plug, 9/16 - 18
G300 O-ring plug, 9/16 - 18
L010 Pressure limiter adjusting screw
L024 Pressure limiter locking nut
L300/L400 Pressure limiter cartridge
G302 O-ring plug, 9/16 - 18
P106 349E
AX152886481964en-000405 | 67
