Open-Q™ 845 µSOM Development Kit User Guide
Reference User Button
Designator
S2500 Volume +
S2502 Volume -/Reset
S2501 GP Switch
S2503 Power ON
Reference LED
Designator
DS2500 Blue LED
DS2501 Green LED
DS2502 Red LED
DS2504 Green LED
DS2503 Red LED

3.7.8 Debug Serial UART over USB J1600 (12)

The UART connection used on the Open-Q 845 is a USB micro B connector (J1600). This debug
UART is available over USB via the FTDI FT232RQ chip on the carrier board. To get the serial
terminal working with a PC, user needs to ensure that the appropriate FTDI drivers are installed. Use
latest FTDI drivers from
item 12 in Figure 1 for the location of J1600 on the carrier board.

3.7.9 USB 3.1 Type C (for ADB) J2300 (11)

The Open-Q 845 carrier board contains one USB 3.1 Type C connection (J2300). This connection is
used for Android debug bridge (ADB) functionality. To get the adb shell, ensure that the board is up
and running and connect the Type C cable between the board and the PC. Type the command adb
root and adb shell on the PC prompt to exercise the adb shell functionality. While ADB utilizes only
the high-speed channel, this USB type C connector supports the USB 3.1 specification including the
super speed data channel. This USB connection is also uses as the charge source when the dev kit is
powered by a battery and battery charging is enabled (see section 3.7.3 above). See item 11 in Figure
1 for the location of J2300 on the carrier board.

3.7.10 USB 3.1 Type A Connector J2400 (5)

The Open-Q 845 carrier board contains one USB Type A connector J2400 situated on the north side
of carrier board, which exposes USB 3.1 host functionality. This USB connection is designed to
provide up to 1A VBUS current for external devices. See item 5 in Figure 1 for the location of J2400
on the carrier board.
If the user intend to use a mini-PCIe card on the dev kit that requires a USB connection (see 3.7.15
below), then the Mini-PCIe USB enable DIP switch S2401 (6) must be switched to closed / ON
(figure below). If the DIP switch is closed, the USB 3.1 Type A connector is not functional.
© Copyright Intrinsyc Technologies Corporation

Table 8. Development Kit Buttons (7)

Table 9. Development Kit LEDs (36)

https://www.ftdichip.com/FTDrivers.htm
Function
Use this button to control or increase the volume.
Use this button to control or decrease the volume. This button can
also be used to reset the board.
This is a general-purpose user button.
Use this button to power on the Open-Q 845 development kit
(when the auto boot configuration not enabled; see 3.7.2 above).
Function
General purpose LED
General purpose LED
General purpose LED
LED indicates input power
LED indicates charging state
instead of system update. See
Version 1.0
21 of 30
