Table 1. List Of Development Kit Features Itemized In The Figure Above - Intrinsyc Open-Q 845 mSOM User Manual

Open-Q™ 845 µSOM Development Kit User Guide

Table 1. List of Development Kit Features itemized in the figure above

Position Feature Description
1 DC Power Supply Jack
2 Power Source Selector
3 Battery Input Header
4 Battery Configuration DIP Switch
5 USB 3.1 Type A Connector
6 Mini-PCIe USB Enable DIP Switch
7 Buttons: General Purpose / Power / Volume Up / Volume Down
8 Audio Headset Jack
9 Haptic Motor Header
10 Audio I/O Header
11 USB 3.1 Type-C connector for ADB
12 USB Serial Debug Console
13 WLAN/BT Channel 0 External Antenna Connector
14 WLAN Channel 1 External Antenna Connector
15 Camera 1 Connector
16 Camera 2 Connector
17 Camera 3 Connector
18 Camera 4 Connector
19 Flash 1 Header
20 Flash 2 Header
21 Sensors Expansion Header
22 Micro SD card socket (on bottom side of Carrier Board)
23 Digital IO Expansion Header
24 Mini-PCIe Card Connector (on bottom side of Carrier Board)
25 SIM Card Socket for Mini-PCIe (on bottom side of Carrier Board)
26 Audio Outputs Expansion
27 Audio Inputs Expansion
28 Audio Codec Module (on top side of Carrier Board underneath
Display Adapter)
29 Power Header
30 Coin Cell Holder
31
Open-Q 845
32
Open-Q 845
33
Open-Q 845
34 On-Board Quiet Thermistor
35 SOM Current Sense Probe Header
36 LEDs: (Charge State / Power / Blue / Green / Red)
37 System Configuration DIP Switch
38 Open-Q LCD Panel
© Copyright Intrinsyc Technologies Corporation
µ
SOM, WLAN/BT CH0 Antenna Connector
µ
SOM, WLAN CH1 Antenna Connector
µ
SOM
Version 1.0
Reference Designator
J400
S300
J300
S301
J2400
S2401
S2501 / S2503 / S2500 /
S2502
J1800
J802
J2000
J2300
J1600
J2701
J2700
J1000
J1100
J1200
J1300
J1001
J1201
J2100
J1500
J2200
J2801
J2800
J1901
J1900
U1700
J700
B300
µ
J2200 (on SOM)
µ
J2201 (on SOM)
RT800
J301
DS2503 / DS2504 /
DS2500 / DS2501 /
DS2502
S2600
