Wireless Device Control Programming: Program Keyfob Buttons
1. Press or to scroll to 'WIRELESS DEVICE CONTROL'. Press
.
2. 'Control Inputs' will be displayed. Press .
3. 'Control Bells' will be displayed. Press .
4. 'Program Keyfob Buttons' will be displayed. Press .
5. Press  or  to select the user to learn and press .
6. Press  or  to select the button to be programmed and press
.
7. Press  or  to select the action of the button and press .
8. Select the area that the keyfob should be programmed in, press
.
NOTE: Keyfobs are learnt in the Master Manager Menu under
'CHANGE CODES'. Refer to the user manual (RINS1527).

4.6 Change Inputs

By default, all inputs are programmed as 'unused', therefore each input installed on the EURO control
panel must be programmed with the desired input type. To enable any programming the Engineer
menu must be exited.
4.6.1 Input Types
Refer to Appendix B (page 43), for all input type options.
Most commonly used input types:
[06] Intruder. [07] Final Exit. [08] Entry Route. [13] Day Alarm.
NOTE 1: If an alarm is triggered from an Entry Route input, it will store for 2 seconds before an
alarm is activated. If a Final Exit input is triggered within this time, the system will select entry
time, rather than an intruder alarm.
NOTE 2: Inputs may be automatically inhibited (omitted) at the time of reinstatement at the end
of confirmation time. Refer to 'Re-Arm Number' in 'CHANGE TIMERS' (page: 21).
4.6.2 Input Areas
The maximum number of areas differs on each EURO control panel, refer to 'System Overview'
(page: 4) for this information.
4.6.3 Input Attributes
The following attributes can be applied to any input:
Chime: When enabled the system loudspeaker(s) will 'chime' when an input is triggered whilst
the alarm panel is disarmed. Chime can be single – sounding once of follow – sounding while the
door is left open. NOTE: The chime can be turned On or Off in disarmed mode by pressing [c]
when all Final Exit inputs are closed.
Omittable: Enables the input to be manually omitted during the setting procedure or from the
user menu whilst the panel is disarmed.
Double Knock: If enabled, an alarm will be generated if this input is triggered twice within the
pre-programmed time window or if the input remains active for that period. The double knock
option does not work on Follow input type.
Dual Trip: An alarm will only be generated if 2 inputs one next to the other with a Dual Trip
attribute have been activated at the same time. This option is very useful for setting up outdoor
perimeter protection.
Normally Open: Both wired and wireless inputs are normally set to Normally Closed. This
attribute allows setting up the input as a Normally Open.
EURO 46, 162 & 280 Programming Manual
Page: 14
WIRELESS DEVICE
CONTROL?
Control Inputs?
Control Bells?
Program Keyfob
Buttons?
User [01]
Select Button
Lock [1]
