2.3 Wireless Input Mappings

2.3.1 Wireless ZEM (EURO-ZEM32-WE)
The wireless ZEM allows 32 inputs which are separated into 4 addresses (each address enables 8
wireless inputs). It is possible to mix the wired and wireless remote expanders. Please refer to
the installation manual (RINS1529) for more information.
2.3.2 Wireless ZEM (EUR-037R)
The Inovonics wireless ZEM is added to the system as if it was a wired ZEM and follows the same
zone mapping as the table on the previous page. Please refer to the installation manual
(RINS1529) for more information.
EURO 46, 162 & 280 Programming Manual
EURO 46 Wireless
End Station -
ZEM0 9-16
ZEM1 17-24
ZEM2 25-32
ZEM3 33-40
ZEM4 -
ZEM5 -
ZEM6 -
ZEM7 -
ZEM8 -
ZEM9 -
ZEM10 -
ZEM11 -
162 Wireless 280 Wireless
-
9-16
17-24
25-32
33-40
41-48
49-56
57-64
65-72
73-80
81-88
89-96
97-104 97-104
Page: 6
-
9-16
17-24
25-32
33-40
41-48
49-56
57-64
65-72
73-80
81-88
89-96
