NEXA MODULAR G2+ AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING
INSTALLATION OF THE DOOR PANEL
Description of the visual signals on the door panel (EL632 G2+ SE / EL642 G2+
Visual signals on the door panel for people with impaired hearing:
- While calling: LED
- During communication: LED
- During door release: LED
- End of communication: LED
- Calling at one door panel while another door panel is communicating (if there is more than one door panel):
LED ' ' will illuminate for
- While calling and the monitor is in "Do not disturb" mode: LED
- While calling (apartment with no monitor
Description of the vocal synthesis (audible signals on the door panel)
Audible signals on the door panel for people with impaired vision.
If vocal synthesis is enabled on the sound module
the following voice messages can be heard on the door panel:
- While calling: "Call is in progress".
- During door release: "Door Opened".
- End of communication: "Communication is finished".
- Calling at one door panel while another door panel is communicating (if there is more than one door panel):
"System is busy, try later".
- While calling and the monitor is in "Do not disturb" mode: "Call is in progress".
- While calling (apartment with no monitor or
Tones mode description (
Tones mode audible signals on the door panel.
If tones mode is enabled on the sound module (see page
the following tones can be heard on the door panel:
- While calling: 2 long tones.
- During door release:
- End of communication:
- Calling at one door panel while another door panel is communicating (if there is more than one door panel):
5 short ton s e .
- While calling and the monitor is in "Do not disturb" mode:
- While calling (apartment with no monitor or
Description of the P1 and P2 external buttons (EL632 G2+ SE / EL642 G2+ sound module):
The connector is located on the right side of the back
Insert the connection cable supplied with module to connect the external call buttons P1 and
P2 of the sound module.
External button P1
P1
COM
P2
will illuminate during in call process.
will illuminate during the communication process.
will illuminate during door release.
will turn off.
3 seconds.
or audio terminal
audible signals on the door panel
1 long tone .
No audible signals.
P1
will illuminate during in call process.
): No visual indication.
(see page 27 for configuration
audio terminal) : "Call is in progress Resident navailable".
) EL632 G2+ SE / EL642 G2+:
27 for configuration),
2 long tones.
audio terminal 2 ): long tones and
sound module.
External button P2
P1
COM
P2
module):
EL632 G2+ SE / EL642 G2+
),
- u
5 short ton s e .
P1
COM
P2
2
P1 P2 BUSBUS
P2
25
:
