NEXA MODULAR G2+ AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING

DESCRIPTION OF THE EL610D BUTTON MODULE

Description of the EL610D button module:

Front.

Module buttons (x10).

Back.

Button connector input/output (x3).

DIP switch (button call code).

Button number.
