NEXA MODULAR G2+ AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING
T P S Y E OF RISER INSTALLATION
Installation with 1 building, 32 monitors, 2 risers and 1 access door panel.
ART 4/
ART 7/
ART 7W/
Apartment 13 Apartment 14
D
M. 9 M. 10
Apartment 5 Apartment 6
Apartment 1 Apartment 2
Distances and cross-sections:
Cable
2
80m
RAP-GTWIN/HF 2x1mm
( )
Max. distance: 1m.
*
Example of installation type:
- With 32 monitors ART 4/G2+ / ART 4 LITE/G2+ monitors.
- With 32 ART 7/G2+ / ART 7 LITE/G2+monitors.
- With 32 ART 7W/G2+ monitors.
RISER 1
ART 4/
ART 7/
ART 7W/
Apartment 15 Apartment 16
EOL
ON
D 4L -G2 +
Apartment 11 Apartment 12
EOL
OFF
Apartment 7 Apartment 8
D 4L -G2 +
EOL
C
OFF
D 4L -G2 + Apartment 3 Apartment 4
EOL
OFF
D 4L -G2 +
A B C D B+ + C D
80m 80m 30m 130m
A
BUILDING 1
ART 4/
ART 7/
ART 7W/
Apartment 29 Apartment 30
M. 25
Apartment 21 Apartment 22
Apartment 17 Apartment 18
End of line
ON
D2 -G2 L + /
D 4L -G2 +
E
B
15m
FA-G2+
( )
*
DPM-G2+
A1 A4
A2 A3
RISER 2
Apartment 31 Apartment 32
EOL
ON
D
D 4L -G2 +
Apartment 27 Apartment 28
EOL
M. 26
OFF
Apartment 23 Apartment 24
D 4L -G2 +
EOL
C
OFF
D 4L -G2 + Apartment 19 Apartment 20
EOL
OFF
D 4L -G2 +
A1=A2=A3=A4= 80m.
E
Lock release
m x. 12 V c/270mA a d
53
