Ambient Integrated Sensor Reference Sheet

Ambient Integrated Sensor
Features
Integrated photocell for closed
•
loop daylighting
• Integrated Passive Infrared (PIR)
motion sensor
Bluetooth 4.2 Low Energy
•
transmitter
Typical Applications
Education and office spaces, other
interior spaces
Models:
WAB: Available option on many
Cooper Lighting luminaires.
Device Type in Mobile App:
Integrated Sensor
The WaveLinx Lite Ambient Integrated Sensor provides wireless control within the light fixture to
reduce wiring, design, and installation time. The sensor provides both occupancy and daylight
control that can be easily configured using the WaveLinx Lite Mobile App.
Out-of-the-Box Operation
Once power is applied, the attached fixture operates via the motion sensors.
•
The occupancy is set for High sensitivity.
•
• If occupied, the fixture will go to 100%.
The fixture will dim to 30% after 10 minutes when the space is unoccupied. The fixture
•
will dim to OFF after 10 additional minutes if the space is still unoccupied.
• The daylight sensor is disabled.
LED flashes green (in sensor window) for 100ms once every 3 seconds when motion is
•
detected.
Provisioned Device Default Behavior
Once provisioned in the WaveLinx Lite Mobile App, the device operates via the daylight and
motion sensors.
• The area's occupancy sensor set
Each occupancy sensor in the set is set for High sensitivity.
•
If occupied, the fixtures of the occupancy set will go to 100%.
•
The occupancy set default hold time is 20 minutes. The fixture will dim to 50% after 10
•
minutes when the space is unoccupied and will dim to OFF after an additional 10
minutes if the space remains unoccupied.
• The daylight sensor remains disabled (must be enabled through the mobile app if daylight
operation is desired).
LED flashes white (in sensor window) for 100ms once every 3 seconds when motion is
•
detected.
Note: This assumes that the device's assigned zone is assigned to an occupancy set and the occupancy
1
set is still at default settings.
LED Behavior
The LED is located beneath the sensor lens.
LED conditions
Flashes green for 100ms, once
every 3 seconds
Flashes white for 100ms, once
every 3 seconds
Flashes white for 10ms every
250ms (fast blink)
LED is OFF
Note: the LED will stop flashing if the light level drops but stays between 50% and 100% of the calibrated
2
light level for 10 minutes OR if the light level falls below 50% of the calibrated light level for 30 seconds.
Note: LED may be difficult to see in very bright areas.
3
Identification Mode Behavior
When placed in 'Blink to Identify' mode, the fixture will turn ON for 1 second, turn OFF for 1
second and repeats this cycle for 15 seconds.
controls the lighting.
1
Meaning
Device is unprovisioned and is detecting motion.
Device is provisioned and is detecting motion
The daylight sensor has exceeded 150% of the calibrated light
level for 30 minutes
2
Device is not detecting motion. If motion is occurring, ensure
device is powered and that the LED has not been disabled
through the mobile app.
3
