Line Voltage Wallstation
Features
• Bluetooth 4.2 Low Energy
transmitter
Commands Supported:
•
• Scene selection
• Raise/lower
• Zone level
• Area OFF
• No Action
Typical Applications
Education and office spaces, other
interior spaces
Models:
WWWL3: 3 Button (WWL3)
WWL3-RL: 3 Button with Raise/Lower
WWL5-RL: 5 Button with Raise/Lower
Custom engraving options
Device Type in Mobile App:
Wallstation
Powered from line voltage (120-277VAC), the WaveLinx Line Voltage Wallstation can be
installed in single or multi-gang configurations. The WaveLinx Line Voltage Wallstation controls
WaveLinx Lite devices by sending control signals through the Bluetooth Mesh network.
Out-of-the-Box Operation
The wallstation will not control lighting out-of-the-box until it has been provisioned.
•
When a button is pressed, the wallstation LED will blink GREEN (ON for 1 second, OFF for 1
•
second) for 10 seconds and then turn OFF to indicate that the wallstation is powered and in
out-of-the-box mode.
Provisioned Device Default Behavior
Once provisioned in the WaveLinx Lite Mobile App, the Line Voltage Wallstation operates
lighting assigned to the same area per the default programming. The LED at the top of the
wallstation will turn ON for 3 seconds when a button is pressed.
LED
location
Note: This command affects all zones in the area.
1
LED Behavior
The LED is located above the top button on the wallstation.
LED conditions
Flashes green (ON for 1 sec.
OFF for 1 sec.) for 10 seconds
Flashes (ON for 1 sec. OFF for 1
sec.) for 15 seconds
Turns ON white for 3 seconds
LED flashes yellow
LED is OFF
Button Function
1 Scene 3: 50%
2 Scene 1: 100%
3
Scene 2: 70%
(WWL5-RL only)
4
Scene 4: 30%
(WWL5-RL only)
Press: increase 1% (per press)
Hold: increase 15% (per second)
Press: decrease 1% (per press)
Hold: decrease 15% (per second)
Scene 0: OFF
Meaning
A button was pressed and the wallstation is not provisioned
The mobile application has been used to place the wallstation
into Identification Mode. The LED will be green on an
unprovisioned wallstation and white on a provisioned
wallstation.
A button was pressed on the provisioned wallstation
The wallstation is being factory reset using the onboard reset.
The LED will be OFF during normal conditions when buttons are
not being pressed if the station is powered
1
1
1
1
1
