Select the site
7: In the calibration screen, use the screen controls to adjust the light level:
• For outdoor applications calibrated at night: Set all closed loop sets to 100% light level.
• For indoor applications: Use the light level adjustment controls to adjust each fixture to the desired light level.
Lighting should respond and assume the defined light level.
8: Optionally, enter the surface light reading using a light meter for reference. This allows current reading fields to approximate more closely
what the light level is at the desired surface. This will have no effect on the calibrated level other than for reviewing or displaying the current
reading. If entering the reading, select either lux or foot-candles to match what was used on the light meter.
9: Tap the calibrate button. A message will briefly show at the bottom of the display to indicate a successful transmission indicating that the
current light level of the sensor will then be stored as the target light level.
54 www.cooperlighting.com
Select the area
Tap 'Daylight'
Adjust the closed loop
set to 100%
If desired, enter the
surface light level reading,
entering the units used
and the value on the on
the light meter
Tap 'Calibrate'
Not connected
Connected
Verify network
connection
Successful
User Manual: WaveLinx Lite (1.5)
Tap the row for the
desired sensor
