Step 7: Repeat The Process For Additional Areas - Cooper Lighting WaveLinx Lite User And Programming Manual

11. Repeat this process for all WaveLinx Lite devices that should belong in this area.
12.If the first device provisioned was a control device (light fixtures with a fixture mount or integrated sensor, for example) remember to move
the device from the default zone to the zone it should operate with. Open the default zone to show the provisioned device. Tap ' ' on the
device row and then select the zone it should be assigned to. If necessary, rename the device.
Tap 'default' zone
Once devices are provisioned and assigned to the area, the devices will begin operating with the default provisioned behavior. See the
"WaveLinx Lite Device Reference Sheets" beginning on page 6 for details on expected device behavior.

Step 7: Repeat the Process for Additional Areas

Once the devices have been provisioned and sorted into their zones for the first area, repeat steps 3 through 6 for any additional areas in the
site. For each area follow the steps in the sections shown below:
• "Step 3: Provision an Area's First Device" on page 20
• "Step 4: Manage the Area Zones" on page 22
• "Step 5: Manage the Area Occupancy Sets" on page 23
• "Step 6: Provision Remaining Area Devices and Assign to Zones" on page 25
If the site devices will be operating from default behavior, setup is complete. Make sure that the site data is synced
to the cloud portal. See "Perform a Site Backup (Sync)" on page 64 for these details.
28 www.cooperlighting.com
Select '-'
Device appears in the
zone. Tap device to
open for renaming
Select the desired
zone
User Manual: WaveLinx Lite (1.5)
