9

PARTS LIST

9.1

Outer Casing

No. Part No.
1 621404011 Right Side Cover
2 621404001 Left Side Cover
3 621632150 Center Cover 60
621632250 Center Cover 75
621632350 Center Cover 100
621632450 Center Cover 130
621632550 Center Cover 160
363013061 Rubber Stopper
4 621390081 Front Guide 60
621261085 Front Guide 75
621271086 Front Guide 100
621281086 Front Guide 130
621291086 Front Guide 160
5 621390092 Rear Guide 60
621261097 Rear Guide 75
621271097 Rear Guide 100
621281097 Rear Guide 130
621291097 Rear Guide 160
6 621400101 Front Writing Panel 60
621410101 Front Writing Panel 75
621420101 Front Writing Panel 100
621430101 Front Writing Panel 130
621440101 Front Writing Panel 160
7 621390042 Rear Writing Panel 60
621261045 Rear Writing Panel 75
621271045 Rear Writing Panel 100
621281045 Rear Writing Panel 130
621291046 Rear Writing Panel 160
8 792800720 Main Board for FC8600
9 682140120 Switching Power Supply Unit
10 363024101 Foot (NT24)
11 682140170 Fan (KLDC12B4-940)
12 621390470 Cutting Mat 60
621261470 Cutting Mat 75
621271470 Cutting Mat 100
621281470 Cutting Mat 130
621291470 Cutting Mat 160
13 621390050 Base, Cutting Mat 60 with base
621261054 Base, Cutting Mat 75 with base
621271054 Base, Cutting Mat 100 with base
621281054 Base, Cutting Mat 130 with base
621291054 Base, Cutting Mat 160 with base
14 792800707 LAN Board
15 621401711 I/F Panel, LAN
16 621404021 Cap, Cover
FC8600-UM-251-9370
Description
9-1
Q'ty Remarks
1
1
1 FC8600-60
1 FC8600-75/
1 FC8600-100
1 FC8600-130
1 FC8600-160
1
1 FC8600-60
1 FC8600-75
1 FC8600-100
1 FC8600-130
1 FC8600-160
1 FC8600-60
1 FC8600-75
1 FC8600-100
1 FC8600-130
1 FC8600-160
1 FC8600-60
1 FC8600-75
1 FC8600-100
1 FC8600-130
1 FC8600-160
1 FC8600-60
1 FC8600-75
1 FC8600-100
1 FC8600-130
1 FC8600-160
1 FC8600
1 LEP150F-48-D40
4
- 60/70:1 100/130/160:2
1 FC8600-60
1 FC8600-75
1 FC8600-100
1 FC8600-130
1 FC8600-160
1 FC8600-60
1 FC8600-75
1 FC8600-100
1 FC8600-130
1 FC8600-160
1
1
2
9 PARTS LIST
Rank
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
A
C
C
B
A
A
A
A
A
C
C
C
C
C
B
D
C
