November 25, 2010 Subject: Can-Am™ Spyder™ RS Predelivery
YEAR
MODEL
®
Spyder
RS SM5
Spyder RS SE5
2011
Spyder RS-S SM5
Spyder RS-S SE5
Underlined text(s) between arrows is (are) modified element(s) to the original publication.
