FMS-2000C

Technical specifications

Intended use
Overvoltage category
Altitude
Pressure range
Alarm range
Display range
Accuracy
Air flow sensor type
Flow control resolution
Displayed pressure resolution
Control capability
I/O Resources
Operating temperature
Operating humidity
Mounting
Alarm indication
Alarm silence
Password protection
Communications protocol
Power requirement
Power consumption
Optional input power supply
Display resolution
Pluggable screw terminal blocks
Display dimensions
(height x width x depth)
Mounted depth
Controller dimensions
(height x width x depth)
Power supply enclosure dimensions
(height x width x depth)
Compliance United States
Canada
Europe
Australia and New
Zealand
Indoor use
II
Up to 2000 m
± 0.2500 in. W.C.
± 0.2500 in. W.C.
± 0.2500 in. W.C.
± 0.5% full scale
Digital differential pressure features no offset, zero drift and is hysteresis free
± 0.0010 in. W.C.
± 0.0001 in. W.C.
Up to 4 independent spaces
4 universal inputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
2 thermistor inputs (NTC Type 2 or 3, 10K at 77° F)
4 digital inputs (active-high or active-low 0 VDC to 5 VDC or 0 VDC to 24 VDC)
4 universal outputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
4 relay outputs (NO or NC contacts 1A at 24 VDC)
32°F to 125°F (0°C to 52°C)
10% to 95% relative humidity, non-condensing
Thin mount for shallow wall cavities, surface mount for mounting to standard single-gang wall box
360° Safety Halo color coded visual, audible alarm
Touchscreen, auto-reset
Up to 50 user passwords with 2 access levels (administrator and restricted)
BACnet MS/TP (to BAS) 76.8k, 38.4k, 19.2k, 9600 baud, Metasys N2 open
24 VAC (nominal, 20 VAC minimum/28 VAC maximum), 50/60 Hz 30 VA power supply, Class 2,
Limited Energy, or LPS
30 VA maximum
Universal 120 VAC/240 VAC-to-24 VAC, 30 VA step-down isolation transformer
24 VAC-to-24 VAC, 30 VA isolation transformer
720 pixels x 1280 pixels
18 AWG to 22 AWG (1.0 mm to 0.6 mm diameter)
5.3 in. x 3.5 in. x 1.17 in. (134.62 mm x 88.9 mm x 29.72 mm)
0.58 in. (14.73 mm)
6.56 in. x 5.5 in. x 1.88 in. (166.62 mm x 139.7 mm x 47.75 mm)
5 in. x 4.7 in. 2.3 in. (127 mm x 119.38 mm x 58.42 mm)
UL Listed to UL 61010-1; FCC 47CFR Part 15; BTL Listed
cUL Listed to CAN/CSA C22.2 NO. 61010-1; ICES-003
CE (EMC Directive) to EN 61326-1
RCM Mark (Australian Radiocommunications Act) to EN 61326-1
