FMS-2000C
Alarms
You can use the Alarms screen within the Settings menu as a shortcut to adjust alarms for each analog input.
Setting up alarms for analog Inputs
1.
On the home screen, tap the Settings icon.
2.
On the SETTINGS screen, scroll down and tap Alarms.
3.
On the ALARMS screen, choose the analog input you want to adjust the alarm for and tap the AI arrow.
4.
On the Alarm Setup screen, switch Alarm Enabled on.
Tap the High Alarm Setpoint arrow.
5.
6.
Enter the High Alarm Setpoint and tap the Checkmark to confirm your settings.
Tap the High Warning Setpoint arrow.
7.
8.
Enter the High Warning Setpoint and tap the Checkmark to confirm your settings.
Tap the Low Warning Setpoint arrow.
9.
10. Enter the Low Warning Setpoint and tap the Checkmark to confirm your settings.
11. To confirm your Alarm Setup settings, tap the Checkmark icon.
Diagnostics
On the Diagnostics screens, you can find information about your particular FMS-2000C Critical Environment Controller model. You can
also find more information to help with troubleshooting during the installation process.
Viewing the About this FMS information
When you contact technical support, use the About this FMS section to reference specific details about your controller. You can also
view the present value, setpoint, deadband, and alarm settings for each of the analog inputs or thermistors you have configured.
To view the device information, complete the following steps:
1.
On the home screen, tap the Settings icon.
2.
On the SETTINGS screen, scroll down and tap Diagnostics.
3.
On the DIAGNOSTICS screen, tap the About this FMS arrow.
4.
On the About this FMS screen, tap the Device Info arrow.
5.
To view the analog input and thermistor settings, tap the Arrow icon.
6.
To return to the About this FMS screen, tap the Checkmark icon.
Accessing real-time view
To help with troubleshooting, use the real-time view screens to see real time conditions. In this view, you can see the real-time
conditions of each of the resources configured to the FMS-2000C controller. This includes the analog input values and their actual
voltages, the analog outputs in percentage, the analog input and output pairs along with the corresponding setpoint, the digital inputs,
the digital outputs, the alarm statuses, and the network variables.
On the home screen, tap the Settings icon.
1.
2.
On the SETTINGS screen, scroll down and tap Diagnostics.
On the DIAGNOSTICS screen, tap the Real-Time View arrow.
3.
4.
On the Real-Time View screen, you can choose the following options:
•
Analog Inputs
•
Analog Outputs
•
Analog I/O Pairs
•
Digital Inputs
•
Relay Outputs
•
Alarm Status
•
Network Variables
•
Overrides
5.
Tap one of the options and tap the Arrow icon to toggle through to the other options.
6.
To return to the DIAGNOSTICS screen, tap the Checkmark icon.
Changing the setpoints and deadband from the real-time view
On the Analog I/O Pairs screen, you can view the analog inputs alongside their associated analog outputs and their corresponding
target setpoints. To change the quick isolation setpoint, complete the following steps:
1.
On the home screen, tap the Settings icon.
2.
On the SETTINGS screen, scroll down and tap Diagnostics.
3.
On the DIAGNOSTICS screen, tap the Real-Time View arrow.
4.
On the Real-Time View screen, tap the Analog I/O Pairs arrow.
5.
To adjust the Setpoint, tap the setpoint arrow of the analog input you want to change.
6.
On the Quick Setpoint screen, enter the new value for the setpoint and tap the Arrow icon.
7.
On the Quick Deadband screen, enter the new value.
8.
To confirm the new settings, tap the Checkmark icon.
53
LIT-12013504
