Initial setup

When the FMS-2000C Critical Environment Controller boots up for the first time, a setup wizard guides you through the initial setup
where you can configure the device language, units of measurement, device orientation, and isolation mode. When you set up the
isolation mode, you can specify the isolation mode available to restricted level users. See Table 3 for definitions of positive, negative and
neutral isolation. You can choose from the following configurations:
• Positive and neutral isolation mode
• Negative and neutral isolation mode
• Positive, negative and neutral isolation mode
Note: Positive, negative and neutral isolation mode is available for rare situations where a room can be either positive or negative.
Table 3: Definitions of isolation modes
Isolation mode
Positive isolation mode
Negative isolation mode
Neutral isolation mode
If your FMS-2000C controller includes two or more differential pressure sensors, you can specify the isolation modes for both a primary
and a secondary space. In a typical application, the FMS-2000C controller can be configured to monitor and control the differential
pressure in an isolation room as well as an adjoining anteroom. The isolation room is the primary monitored space and the anteroom
is the secondary monitored space. Use the primary sensor input or analog input 1 (AI-1) for a primary monitoring and control capability.
Use the secondary sensor input or analog input 2 (AI-2) for a secondary monitoring and control capability.

Completing the initial setup

The FMS-2000C display boots up in portrait orientation by default. You can change this to landscape orientation in the initial setup in
step four. The first screen that appears in the initial setup is the Language screen.
1. On the Language screen, scroll to your preferred language and tap the Checkmark icon.
On the Global screen, expand Units and tap to select whether values display as Imperial or Metric.
2.
3. Expand Device Orientation and tap to select Portrait or Landscape screen orientation.
Collapse Device Orientation and tap the Checkmark icon to save the settings.
4.
5. On the Isolation Mode screen and choose from the following options:
Positive & Negative
•
• Positive Only
Negative Only
•
6. Tap the Checkmark icon to save the settings.
7. If your FMS-2000C controller came with two sensors, you get the option to set up a primary and a secondary space. To set up the
isolation mode for the primary and secondary space, expand Primary and Secondary. Choose from the following options:
• Positive & Negative
• Positive Only
• Negative Only
8. Collapse Primary and Secondary and tap the Checkmark icon to save the settings.
9. Tap Proceed to complete the initial setup.
Note: You can make changes to your initial settings in the Settings menu any time.
The differential pressure of the monitored space is positive with respect to the reference space.
The differential pressure of the monitored space is negative with respect to the reference space.
The differential pressure of the monitored space is zero or near zero with respect to the reference space.
Definition
