5.3.5 Changing Parameter Settings
Parameter settings can be accessed and changed from the
[Quick Menu] or from the [Main Menu]. The [Quick Menu]
only gives access to a limited number of parameters.
1. Press [Quick Menu] or [Main Menu] on the LCP.
2.
Press [
groups, press [OK] to select a parameter group.
3.
Press [
press [OK] to select a parameter.
5 5
4.
Press [
setting.
5. Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter Status, or press
[Main Menu] once to enter Main Menu.
View changes
Quick Menu Q5 - Changes Made lists all parameters
changed from default settings.
•
The list shows only parameters which have been
changed in the current edit-setup.
•
Parameters which have been reset to default
values are not listed.
•
The message Empty indicates that no parameters
have been changed.
5.3.6 Restoring Default Settings
NOTICE
Risk of loosing programming, motor data, localisation,
and monitoring records by restoration of default
settings. To provide a back-up, upload data to the LCP
before initialisation.
Restoring the default parameter settings is done by initiali-
sation of the frequency converter. Initialisation is carried
out through 14-22 Operation Mode (recommended) or
manually.
•
Initialisation using 14-22 Operation Mode does not
reset frequency converter settings such as
operating hours, serial communication selections,
personal menu settings, fault log, alarm log, and
other monitoring functions.
•
Manual initialisation erases all motor,
programming, localisation, and monitoring data
and restores factory default settings.
24
Operating Instructions
▲ ▼
] [ ] to browse through the parameter
▲ ▼
] [ ] to browse through the parameters,
▲ ▼
] [ ] to change the value of a parameter
Danfoss A/S © Rev. 2014-02-06 All rights reserved.
Recommended initialisation procedure, via
14-22 Operation Mode
1. Press [Main Menu] twice to access parameters.
2. Scroll to 14-22 Operation Mode and press [OK].
3. Scroll to Initialisation and press [OK].
4. Remove power to the unit and wait for the
display to turn off.
5. Apply power to the unit.
Default parameter settings are restored during start-up.
This may take slightly longer than normal.
6. Alarm 80 is displayed.
7. Press [Reset] to return to operation mode.
Manual initialisation procedure
1. Remove power to the unit and wait for the
display to turn off.
2. Press and hold [Status], [Main Menu], and [OK] at
the same time while applying power to the unit
(approximately 5 s or until audible click and fan
starts).
Factory default parameter settings are restored during
start-up. This may take slightly longer than normal.
Manual initialisation does not reset the following frequency
converter information:
•
15-00 Operating hours
•
15-03 Power Up's
•
15-04 Over Temp's
•
15-05 Over Volt's

5.4 Basic Programming

5.4.1 Commissioning with SmartStart

The SmartStart wizard enables fast configuration of basic
motor and application parameters.
•
At first power up or after initialisation of the
frequency converter, SmartStart starts automat-
ically.
•
Follow on-screen instructions to complete
commissioning of the frequency converter.
Always reactivate SmartStart by selecting Quick
Menu Q4 - SmartStart.
•
For commissioning without use of the SmartStart
wizard, refer to chapter 5.4.2 Commissioning via
[Main Menu] or the Programming Guide.
NOTICE
Motor data are required for the SmartStart set-up. The
required data are normally available on the motor
nameplate.
MG16E302
