Specifications
380–480 V
Enclosure
type
A2
A3
B3
B4
C3
C4
A4
A5
B1
8 8
B2
C1
C2
Table 8.13 380–480 V, Enclosure Types A, B and C
70
Power [kW] Recommended
fuse size
1.1–4.0 gG-10 (1.1–3)
gG-16 (4)
5.5–7.5 gG-16
11–18 gG-40
22–37 gG-50 (22)
gG-63 (30)
gG-80 (37)
45–55 gG-100 (45)
gG-160 (55)
75–90 aR-200 (75)
aR-250 (90)
1.1–4 gG-10 (1.1–3)
gG-16 (4)
1.1–7.5 gG-10 (1.1–3)
gG-16 (4–7.5)
11–18.5 gG-40
22–30 gG-50 (22)
gG-63 (30)
37–55 gG-80 (37)
gG-100 (45)
gG-160 (55)
75–90 aR-200 (75)
aR-250 (90)
®
VLT HVAC Drive Instruction Manual
Recommended
Max. fuse size
gG-25
gG-32
gG-63
gG-125
gG-150 (45)
gG-160 (55)
aR-250
gG-32
gG-32
gG-80
gG-100
gG-160
aR-250
MG11AJ22 - Rev. 2013-09-13
Recommended circuit Max. trip level [A]
breaker (Moeller)
PKZM0-25
PKZM0-25
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
PKZM0-25
PKZM0-25
PKZM4-63
NZMB1-A100
NZMB2-A200
NZMB2-A250
25
25
50
100
150
250
25
25
63
100
160
250
