Commissioning
Key
6 Status
7 Quick Menu
8 Main Menu
9 Alarm Log
5 5
Table 5.2 Legend to Figure 5.1, Display Menu Keys
C. Navigation Keys and Indicator Lights (LEDs)
Navigation keys are used for programming functions and
moving the display cursor. The navigation keys also provide
speed control in local (hand) operation. There are also three
adjustable frequency drive status indicator lights in this area.
Key
10 Back
11 Cancel
12 Info
13 Navigation
Keys
14 OK
Table 5.3 Legend to Figure 5.1, Navigation Keys
Indicator
15 ON
16 WARN
17 ALARM
Table 5.4 Legend to Figure 5.1, Indicator Lights (LEDs)
26
VLT
Function
Shows operational information.
Allows access to programming parameters
for initial set-up instructions and many
detailed application instructions.
Allows access to all programming
parameters.
Displays a list of current warnings, the last
ten alarms, and the maintenance log.
Function
Reverts to the previous step or list in the
menu structure.
Cancels the last change or command as long
as the display mode has not changed.
Press for a definition of the function being
displayed.
Use the four navigation keys to move between
items in the menu.
Use to access parameter groups or to enable a
choice.
Light Function
Green The ON light activates when the
adjustable frequency drive receives
power from AC line voltage, a DC
bus terminal, or an external 24 V
supply.
Yellow When warning conditions are met,
the yellow WARN light comes on
and text appears in the display area
identifying the problem.
Red A fault condition causes the red
alarm light to flash and an alarm
text is displayed.
®
HVAC Drive Instruction Manual
D. Operation Keys and Reset
Operation keys are located at the bottom of the LCP.
Key
18 Hand On
19 Off
20 Auto On
21 Reset
Table 5.5 Legend to Figure 5.1, Operation Keys and Reset
NOTICE!
The display contrast can be adjusted by
pressing [Status] and [
5.3.3 Parameter Settings
Establishing the correct programming for applications often
requires setting functions in several related parameters.
Details for parameters are provided in 9.2 Parameter Menu
Structure.
Programming data are stored internally in the adjustable
frequency drive.
•
For backup, upload data into the LCP memory
•
To download data to another adjustable frequency
drive, connect the LCP to that unit and download
the stored settings
•
Restoring factory default settings does not change
data stored in the LCP memory
5.3.4 Uploading/Downloading Data to/from
the LCP
1. Press [Off] to stop the motor before uploading or
downloading data.
2. Go to [Main Menu] 0-50 LCP Copy and Press [OK].
3. Select All to LCP to upload data to LCP or select All
from LCP to download data from the LCP.
MG11AJ22 - Rev. 2013-09-13
Function
Starts the adjustable frequency drive in local
control.
•
An external stop signal by control input or
serial communication overrides the local
hand on
Stops the motor but does not remove power
to the adjustable frequency drive.
Puts the system in remote operational mode.
•
Responds to an external start command by
control terminals or serial communication
Resets the adjustable frequency drive
manually after a fault has been cleared.
▲ ▼
]/[ ] keys.
