Videx IPVK Series Installation Handbook page 8

IPVK/6296 Series IP videokit
Art. 4533
IP speaker unit module for VIDEX IP System
ADHESIVE GASKET PLACEMENT
seal as shown in Fig. 14.
Apply the
Y
ANTI TAMPERING LOCKS FIXING
Fit the anti-tampering locks
HOW TO REMOVE/INSERT THE CARD NAME HOLDER
• To avoid damage to the module front plate, mask the side that
will be in contact with the screwdriver blade;
• Insert the screwdriver (flat side) into the card-holder hole as
shown in Fig. 16;
• Move the screwdriver to the left as shown in Fig. 17 to extract
the card name holder;
• Edit the card name then replace it inside the holder and refit:
insert the holder inside its housing from the left or right side
then push the other side until it clips into place.
CONNECTION TERMINAL SIGNALS
Active low output enabled when the
SL
external video input is in use
EXT
GND Composite video signal ground reference
CAMERA
V
Composite video signal input
A
RS-485 Connection (termination adjusted
B
RS485
through the JP1 jumper)
GND
+12V
POWER 12Vdc 400mA power supply input
GND
Active low input 1 (when enabled activate
IN1
the programmed output)
INPUTS Active low input 2 (when enabled activate
IN2
the programmed output)
GNDI Ground for IN1 and IN2 inputs
RX–
Ethernet Connection Orange (568A)
RX+
Ethernet Connection White/Orange (568A)
ETHERNET
TX–
Ethernet Connection Green (568A)
TX+
Ethernet Connection White/Green (568A)
C2
Relay 2 common contact
NC2
Relay 2 normally closed contact
RELAY 2
NO2 Relay 2 normally open contact
C1
Relay 1 common contact
NC1
RELAY 1 Relay 1 normally closed contact
NO1 Relay 1 normally open contact
IPVK/6296 Series - Installation handbook
as shown in Fig. 15.
W
Vac/dc
Y
Fig. 14
Fig. 16
TECHNICAL SPECIFICATION
Video codec:
Supported resolutions: 352x288 (CIF) used in SIP standard
Audio codec:
Sampling frequency:
SIP compatibility:
Power Supply:
Power consumption:
Working Temperature: -10 +50 °C
MAXIMUM ILLUMINATION DISTANCE FROM CAMERA AT NIGHT
The illumination LED's within the camera will
illuminate the visitor when they are within
50 cm of the camera.
Max
12-24
CLEANING OF THE PLATE
0.4A
Use a clean and soft cloth. Use moderate warm water or non-ag-
gressive cleansers.
Do not use:
• abrasive liquids;
• chlorine-based liquids;
• metal cleaning products.
- 8 -
G
Fig. 15
Fig. 17
H.263
H.263+
mode
320x240 used between Videx devices
and app
176x144 (QCIF) used in SIP standard
mode
G.711 μ-law, A-law
8 khz
SIP 2.0
12Vdc - 400mA
Stand by: 250mA
Operating: 380mA
66550062-EN - V5.0 - 31/10/19
W
MAX 50 cm
