Videx IPVK Series Installation Handbook page 7

IPVK/6296 Series IP videokit
Art. 4533
IP speaker unit module for VIDEX IP System
4533 DOOR PANEL RESET FOR ONE OR TWO APARTMENT VIDEO KIT
The door panel is required to be open for this procedure.
1. Power down the door station;
2. Restore the power keeping pressed Call Button 1 (Bottom button on a 2 button panel Fig. 7) until the
led's start flashing together (Fig. 8)*;
3. Press the boot loader button once (inside the panel) (Fig. 9), the red
ues flashing together with the yellow
4. Press call button 1 (Fig. 11) for a one way videokit otherwise press call button 2 (Fig. 12) for a two way video kit;
5. When the button is released, the door panel emits one long beep for one way videokit or two long beeps for two way videokit
then reboots with the new settings.
* If the door panel is connected to the cloud, the
to the door panel settings.
Fig. 7 Keep pressed button 1
Fig. 10
Speech & Key LEDs flashing
ENABLE BOOTLOADER MODE
In case of firmware update failure (i.e. because of mains failure
or cable disconnection during the update etc.) and the door
panel is no longer recognised by the Videx IP Wizard software,
you can try to restore it by manually putting it into boot mode.
It is strongly recommended that this operation is carried out by a
qualified engineer and in any case after a contact with Videx support.
• Disconnect the door panel from the power supply.
• Press and keep pressed the
then connect again the power supply source.
• The door panel will go into boot mode which is indicated by
the four LED's flashing alternatively (Fig. 13).
• Now proceed using the utility "VidexFirmwareUpdater.exe" to
upload the firmware to the device.
• If the update process terminates correctly, the device should be restored and ready to work.
• If the device still does not work, please contact the supplier to proceed according to the warranty terms.
IPVK/6296 Series - Installation handbook
LED (Fig. 10);
LED will flash twice and the panel will reboot without changing your settings. In this case, the IP wizard must be used to make any changes
Fig. 8 Bell & Key LEDs flashing
Fig. 11
One way videokit
I button (Fig. 2 on page 5)
LED will stop flashing while the green
Fig. 9
of the module)
Fig. 12
Fig. 13 Door panel in BOOTLOADER mode
