Videx IPVK Series Installation Handbook page 21

IPVK/6296 Series IP videokit
Art. 6296
IP Videophone for VIDEX IP System
OPERATION VIDEOPHONE'S BUTTONS
TO ANSWER A CALL & OPEN THE DOOR
• On an incoming call the videophone rings and the display shows the initialising screen (Fig. 28), the video coming from the door
panel is then shown (Fig. 29).
• Pick up the handset to start the conversation with the visitor (Fig. 30).
• While the conversation is in progress, take a picture of the visitor manually, press and keep pressed
shows camera icon with date & time (Fig. 31).
• A visitor picture is automatically taken on any incoming call answered or not.
button to open the door (Fig. 32)*.
• Press the
*Note that the relay activated depends on the configuration of the button, as factory default it activates relay 1 of the active door panel.
Main Entrance
Fig. 28
Incoming call initialising the video
Main Entrance
22/06/2017
Fig. 31 Taking a picture of the visitor
TO ENABLE PRIVACY SERVICE
When the service is enabled the videophone doesn't receive external or internal calls.
button to enable the privacy service (Fig. 33). The relevant LED illuminates.
• Press the
• To disable the service proceed again as above (Fig. 34)
MAIN MENU
Fig. 33 Privacy service enabled
IPVK/6296 Series - Installation handbook
Main Entrance
Fig. 29
Incoming call showing the video
Main Entrance
18:45
Fig. 32 Activating the door relay
15:30
Privacy mode enabled
M.E. Pedestrian Gate
MAIN MENU
Fig. 34 Privacy service disabled
- 21 -
button until the display
Main Entrance
Fig. 30
The conversation starts after the
handset is picked up
Privacy mode disabled
66550062-EN - V5.0 - 31/10/19
15:30
