IPVK/6296 Series IP videokit
Index
System components and available versions ................................................................................................................................ 3
Art. 4533 IP speaker unit module .................................................................................................................................................. 5
Art. 4901 Digital codelock module ................................................................................................................................................ 9
4000 Series surface and flush mounting door station installation .......................................................................................... 13
Art. 6296 IP Videophone for VIDEX IP System ........................................................................................................................... 15
6200 Series Videophone wall mounting instructions ............................................................................................................... 28
Windows setup static IP address ................................................................................................................................................. 29
VX IP WIZARD Wizard configuration software for VIDEX IP System ........................................................................................ 31
Installation diagrams ................................................................................................................................................................... 48
INSTALLATION DIAGRAMS NOTES AND SUGGESTIONS
• All diagrams refer to all kit versions: flush or surface.
• Dashed connections refer to optional connections ("Local
bell", "Push to exit" & "Door monitor").
• Some diagrams show how to connect a 12Vdc electric lock:
these directions are suitable for all diagrams in this manual.
• All diagrams shown are valid for systems with surface or flush
mount door station.
• To install this equipment are required expertises in the field
of information and networking technologies.
DECLETION OF RESPONSIBILITY
This manual has been written and revised carefully. The instruc-
tions and the descriptions which are included in it are referred
to VIDEX parts and are correct at the time of print. However, sub-
sequent VIDEX parts and manuals, can be subject to changes
without notice. VIDEX Electronics S.p.A. cannot be held respon-
sible for damages caused directly or indirectly by errors, omis-
sions or discrepancies between the VIDEX parts and the Manual.
WE RECOMMEND
This equipment is installed by a Competent Electri-
cian, Security or Communications Engineer
IPVK/6296 Series - Installation handbook
To download the programming software
VX IP Wizard and obtain the latest firmware
and manuals please visit the following web-
site and register
https://service.videx.it/
MORE INFORMATION ON PAG. 46 OF THIS MANUAL.
- 2 -
66550062-EN - V5.0 - 31/10/19
