15 Sub Area
Control
16 Fault
17 Arming Control
18 Shunt
19 Disarm Only*
20 Keyswitch
Latched*
21 Entry Shock
22 Line Fault
23 Keyswitch
Pulsed*
PCX 46 Programming Reference
Active when armed or disarmed. Communicator: Sub-area Armed/Disarmed
event (CID 402/401). Sub Area may be armed or disarmed by proximity tag
or zone/input where a keyswitch can be wired. To each sub area can be
allocated a number of zones/inputs creating the sub-area configuration.
Active when armed or disarmed: Audible Response: internal sounder.
Communicator: Fault event.
If armed only: Activates 'Global Fault 1' output type.
If disarmed or armed: Activates 'Global Fault 2' output type.
Note that the 'Technical Fault' output type is triggered every time a fault is
active including when the fault zone/input type is active.
Active during arming procedure: No audible or communicator response.
Prevents system being armed whilst the zone/input is in an active state.
Active at all times: No audible or communicator response.
It is possible to associate zones/inputs to the shunt zone/input. It normally
is connected to a key-switch (or equivalent) and when On or Off it shunts or
un-shunts the zones/inputs assigned to it. Associated outputs are available
to follow this zone/input type.
Creating a Shunt Group: A shunt group may consist of any number of
zones/inputs programmed as Instant, Tamper, 24hr and Follow types. These
must all be allocated in the same area.
NOTE: These zones/inputs will need to be programmed before allocated to
the shunt zone/input.
The zones/inputs in the shunt group/list will only activate after 10 seconds
of the nominated shunt zone/input.
Example: If zone/input 1 is programmed as 'Shunt zone', and zones/inputs
2 and 3 are programmed as "24hr", then once zone/input 1 has been
opened, after 10 seconds zones/inputs 2 and 3 become active.
Action 1: Shunt Zone/Input closed
Status: Zones/Inputs within the shunt list are Shunted ( Disarmed)
Outputs: 'Follow Zone/Input' PGM output On
Action 2: Shunt Zone/Input opened
Status: After 10 seconds zones/inputs in the shunt list are going to activate,
i.e. become Un-shunted (Armed)
Outputs: 'Follow Zone/Input' PGM output OFF. The 'Shunt Fault' PGM output
is on for 10 seconds.
Action 3: Shunt Zone/Input opened with active detector from the shunt list
Status: After 10 seconds zones/inputs in the shunt list are going to activate,
i.e. become Un-shunted (Armed)
Outputs: 'Follow Zone/Input' PGM output OFF. The 'Shunt Fault' (type 36)
PGM output pulses until the detector closes.
Active when armed: Accepts zone/input from keyswitch (or equivalent) to
disarm the area(s) assigned to it.
Accepts zone/input from keyswitch (or equivalent) to arm/disarm the area
assigned to it. Arming includes normal exit time, etc. Requires latching
switch action. Normal operation is open circuit to arm the system, and close
circuit to disarm the system.
Active when system armed: This zone/input type is advised to be used in
conjunction with an Entry Delay input. The Entry Delay input is a door
contact on the initial entry door, and the Entry Shock zone/input is a non-
latching shock sensor fitted to the door frame in the vicinity of the lock. If
the door is forced a Burglary alarm will be generated immediately.
Active when fail. This zone/input type is used to detect external
transmission equipment line fail (output). If activated will give a line fault
alarm, and will signal telecom line fault on expiry of line fault timer. It can
be used in conjunction with CCTV input (type 39)
Accepts zone/input from keyswitch to arm/disarm the area(s) assigned to it.
Requires momentary action switch to toggle arm/disarm state.
Note that Grade 1 operation only allows arming from the push button, but
requires means to abort arming (not to disarm)
