Pyronix PCX 46 App Programming Reference Manual page 10

29 Interior
32 Flood
39 CCTV
40 Perimeter
41 Patrol / Keybox
42 Medical
43 Entry Delay 2
#These zone/inputs cannot be bypassed.
*Use of zones/inputs 19, 20 and 23 will make the system unable to comply with EN50131-1 Security
Grade 2 or 3.
$ Ensure that these zones/inputs are used on an entry/exit route
Choose Zone/Input
Choose an input to program.
Zone In Area
Enter the areas you would like the input to operate in.
Common Zone
In certain situations, a 'common' area may be needed. A common area is an area that only arms if
other specific areas are armed.
Example: A reception in a building will only need to be armed if the offices and warehouse are armed.
If the office is armed, but the warehouse isn't, then the reception would still need to be inactive so
people would be able to leave the premises. One zone/input can be allocated to one or more areas.
In this example the zone/inputs located in the reception area will be in the offices and warehouse
areas and have the common attribute activated.
Area A: Office – Zones/Inputs 1, 2, 3, 4 and 8. Area B: Warehouse – Zones/Inputs 5, 6, 7 and 8.
Zone/Input 8: The detector connected to this zone/input is going to be the zone/input located in the
Reception and is common to Area A and Area B. Zone/Input 8 will only be active if the Area A and
Area B are both armed. If one of them is disarmed then zone/input 8 will not be active either.
5.1.1 Zone Attributes?
No Attribute
1 Chime
2 Allow
Bypass
PCX 46 Programming Reference
This will work the same as an instant type zone/input, the only difference is
that when CID reporting is programmed then any inputs that are
programmed as Interior will report CID event 132.
This zone/input type will work as a 24hr input, any zones/inputs that are
programmed for Flood will activate the external siren and will report CID
event 113.
Active at all times: No audible alarm or communicator response.
The CCTV zone/input should be connected to an external detector located
next to a CCTV camera. An output can be programmed to follow this
zone/input and the output should be connected to a CCTV recording,
transmission or other device. A zone/input programmed as "Line Fault"
(type 22) should also be connected to an output of the CCTV transmission
Device. If the CCTV transmission line has been cut or missing the 'Line
Fault' zone/input will activate. Following to this at each activation of the
CCTV zone/input the panel will signal CID events for 'Silent Burglary' and
Line Fault. No audible alarm will be created. If the Line Fault is not active it
will just log the activations of the CCTV zone/input into the event log.
This will work the same as an instant type zone/input, the only difference is
that when Contact ID reporting is programmed then any zones/inputs that
are programmed as Perimeter will report Contact ID event 131.
This zone/input type will work similarly to a switcher zone/input, it does not
trigger an alarm but will report Contact ID event 250 and is also a useful
zone/input type when an output is required to follow the Keybox type zone.
This is a 24 Hrs type zone/input it will activate the external sounder and
report a Contact ID event 100.
$ Any zone/input programmed as Entry Delay 2 will act as zone type 07, but
the associated entry timer will use Entry Timer 2, rather than Entry Timer 1.
Operation for both wired and wireless inputs
When enabled the system loudspeaker(s) will 'chime' when an input is
triggered whilst the alarm panel is disarmed. Chime can be single –
sounding once of follow – sounding while the door is left open. NOTE: The
chime can be turned On or Off in disarmed mode by pressing [c] when all
Entry Delay inputs are closed.
Enables the input to be manually bypassed during the arming procedure or
from the user menu whilst the panel is disarmed.
Page: 10
