5.6 Program Timers?

Timers Description
Entry Time 1 Programmes the entry time for each area. If entry time is started at a
Entry Time 2 door programmed in multiple areas, the longest time will apply. Entry
time 1 will apply to any zones/inputs programmed as "Entry Delay 1"
type, and Entry Time 2 will apply to any zones/inputs programmed as
"Entry Delay 2" type. Ensure that timer is no longer than 45 seconds in
order to comply with EN50131-1.
Exit Time Programs the exit time for each area.
Bell Time Cut off time for external sounder. Separate for each area. Repeat above
steps for each of the
Bell Delay Delay after burglary alarm before bell activation.
NOT valid within 3 minutes of final arm, or after entry time started. If
'Silent 1st Alarm' selected in alarm responses, delay commences at
confirmed alarm.
Strobe Time The duration of time the strobe output remains live after the bell time
ends, '99' means endless.
Number Number of times system re-arms after bell time ends. Re-arm number
Re-arms applies to each area, and does not affect emergency alarms. '9' = 'always
re-arm'.
AC Fail Time delay before mains failure or technical alarm signalled. '250' = never
Delay alarms. System change-over to battery supply and associated 'alert'
indication is always immediate. Mains Fail message on keypad not
permitted until valid code entry.
Double Length of filter period applied to inputs with 'Double Knock' input
Knock attribute.
Entry Alarm Delays 'Burglary' alarm signalling if an alarm is generated by deviation
Signal Delay from the entry route. Delay Send Entry must be programmed for a
minimum of 30 seconds to comply with EN50131-1.
Line Fault Duration of Telecom (GSM) Line Fault before 'Line Fault' alarm triggered,
Delay '250' endless.
Arm Fail If a system has not been armed within the entry delay time, for example
Time door left open the Arm Fail Time will take over and at the expiry of this
time an alarm will be created. This time should be longer than the Entry
Delay time.
Guard Code Minimum time an alarm must have been present before a 'Guard' code
Delay will be accepted to disarm.
Fire Bell Cut off time for fire alarm. '99' = endless.
Time
Activity This is used in conjunction with the input attribute 'Activity Zone', and will
Timer monitor the chosen zone/input for the selected number of days. At
expiration of timer, and if the zone/input has not opened within that time,
then this will be stored in the panel log. Non Activity fault and there will
be an output activated if programmed to it. Send SMS message if "Special
Log" is on.
Activity This is used in conjunction with the input attribute 'Activity Zone', and will
Hours monitor the chosen zone/input for the selected number of hours. At
expiration of timer, and if the zone/input has not opened within that time,
then this will be stored in the panel log. Non Activity fault and there will
be an output activated if programmed to it. Send SMS message if "Special
Log" is on.
Pulsed This option sets up the duration of the pulse of an output programmed as
Burglar Any "Pulsed Burglary Any" activates after a burglary alarm.
PCX 46 Programming Reference
areas programmed on your system.
PCX 46 App
Page: 17
Options
0-255
seconds
0 – 255
seconds
02 – 15
minutes
0-20
minutes
0-99
minutes
0 – 9
0-250
minutes
0 – 75
seconds
0-255
seconds
0-250
seconds
0-255
seconds
0-10
minutes
1 – 99
minutes
0-14
days
00-23
hours
0-255
seconds
