Your First Program
The example programs that you will type into the BASIC Stamp Editor and download to
the BASIC Stamp will always be shown with a gray background. Here is an example:
Example Program: HelloBoeBot.bs2
' Robotics with the Boe-Bot - HelloBoeBot.bs2
' BASIC Stamp sends a text message to your PC/laptop.
' {$STAMP BS2}
' {$PBASIC 2.5}
DEBUG "Hello, this is a message from your Boe-Bot."
END
You will enter this program into the BASIC Stamp Editor. Some lines of the program are
made automatically by clicking buttons on the toolbar. Other lines are made by typing
them in from the keyboard.
Chapter 1: Your Boe-Bot's Brain · Page 23
Figure 1-34
6-9VDC
9 Vdc
Messages from the
Battery
BASIC Stamp to Your
Computer
TM
1
Sout Vin
Sin Vss
ATN Rst
Vss Vdd
P0 P15
P1 P14
U1
P2 P13
P3 P12
P4 P11
P5 P10
P6 P9
P7
P8
