For each motion block, there are 4 digital signals which are influenced depending on
the status of the motion order and can be used for indicating the status of motion
orders:
Digital Signal 1
Digital Signal 2
Digital Signal 3
Digital Signal 4
To control logic functions or for transmission via the system bus (available if exten-
sion module with system bus interface is connected) the following signals can be
selected:
891 – Motion-Block Digital Signal 1
892 – Motion-Block Digital Signal 2
893 – Motion-Block Digital Signal 3
894 – Motion-Block Digital Signal 4
895 – Motion-Block Digital Signal 1 inverted
896 – Motion-Block Digital Signal 2 inverted
897 – Motion-Block Digital Signal 3 inverted
898 – Motion-Block Digital Signal 4 inverted
Operation modes for digital outputs:
62 – Motion-Block Digital Signal 1
63 – Motion-Block Digital Signal 2
64 – Motion-Block Digital Signal 3
65 – Motion-Block Digital Signal 4
162 – Motion-Block Digital Signal 1 inverted
163 – Motion-Block Digital Signal 2 inverted
164 – Motion-Block Digital Signal 3 inverted
165 – Motion-Block Digital Signal 4 inverted
The statuses of the digital signals can be influenced (set, reset or leave unchanged)
when the following events occur:
− Reference value reached
− Start of motion block
− End of motion block
Digital output signals of motion blocks
Digital signal from the motion block
Assign operation mode
Digital Signal 1
1218
Digital Signal 2
1219
Digital Signal 3
1247
Digital Signal 4
1248
04/08
04/08
Digital signals for indication of status of motion or-
ders
1218
1219
1247
1248
0 - Start: --- Ref.reached: --- End: ---
1 - Start: on Ref.reached: --- End: ---
2 - Start: off Ref.reached: --- End: ---
10 - Start: --- Ref.reached: on End: ---
12 - Start: off Ref.reached: on End: ---
20 - Start: --- Ref.reached: off End: ---
21 - Start: on Ref.reached: off End: ---
100 - Start: --- Ref.reached: --- End: on
102 - Start: off Ref.reached: --- End: on
120 - Start: --- Ref.reached: off End: on
121 - Start: on Ref.reached: off End: on
200 - Start: --- Ref.reached: --- End: off
201 - Start: on Ref.reached: --- End: off
210 - Start: --- Ref.reached: on End: off
212 - Start: off Ref.reached: on End: off
Application manual Positioning
Application manual Positioning
Output signals
Operation modes for digital outputs:
62 - Motion-Block Digital Signal 1
63 - Motion-Block Digital Signal 2
64 - Motion-Block Digital Signal 3
65 - Motion-Block Digital Signal 4
Signal sources for control
of logic functions or
transmission via bus system:
891 - Motion-Block Digital Signal 1
892 - Motion-Block Digital Signal 2
893 - Motion-Block Digital Signal 3
894 - Motion-Block Digital Signal 4
