Set the next motion block, stop of the drive or error switch-off for an
event:
By entering one of the listed values for parameters
−
−
−
−
−
the next motion block or user-defined behavior in the case of events can be se-
lected. Errors in the motion sequence can be identified quickly by emergency stop,
stop and the error switch-off function.
Next motion block
1213, 1215, 1217,
1262, 1265
60
60
Delay: Next Motion Block
Event 1: Next Motion Block
Event 2: Next Motion Block
Int.-Event 1: Next Motion Block
Int.-Event 2: Next Motion Block
-3 -
Em. stop, error
(Minus 3)
-2 -
Stop, error
(Minus 2)
-1 -
Error Switch-Off
(Minus 1)
0 - Disabled
1 ... 32
Parameter
No. Description
1214 Event 1
1215 Event 1: Next Motion Block
1216 Event 2
1217 Event 2: Next Motion Block
-
1260 Interrupt Event 1
1261 Int.-Event 1: Eval.-Mode
1262 Int.-Event 1: Next Motion Block
1263 Interrupt-Event 2
1264 Int.-Event 2: Eval.-Mode
1265 Int.-Event 2: Next Motion Block
Application manual Positioning
Application manual Positioning
1213
1215
1217
1262
1265
Function
The drive is stopped via
after that, error message "F15XX User-Defined Error
in Motion Block" is output.
The drive is stopped at the active deceleration ramp,
after that, error message "F15XX User-Defined Error
in Motion Block" is output.
The drive is switched off, after that, error message
"F15XX User-Defined Error in Motion Block" is out-
put.
Factory setting. Processing of next motion blocks
is switched off.
The corresponding motion block is executed.
Min.
Logic signal or digital input 7 - Off
-3
Logic signal or digital input 7 - Off
-3
Logic signal or digital input 7 - Off
1
-3
Logic signal or digital input 7 - Off
1
-3
Emergency Ramp
1179,
Setting
Max. Fact. sett.
32 0 - Disabled
32 0 - Disabled
1 - Level
6
Controlled
32 0 - Disabled
1 - Level
6
Controlled
32 0 - Disabled
