4.4.- Oil installation

The TRO Evolution System boiler is supplied with a Domestic gas-oil burner (10) (see model in
Technical Characteristics). To install the oil line, proceed in accordance with the burner
instructions enclosed with this manual (see Burner section). The oil line installation and start-up
of the burner must be carried out by qualified, authorised personnel.

4.5.- Combustion products exhaustion

The installation of exhaustion of the products of combustion has to be carried out by
qualified personnel staff and it will fulfill the requirements demanded in the legislation and
effective regulatory schemes.
The TRO Evolution System boilers are balanced flue oil boilers, so that the combustion
products exhaustion is carried out by means of an outlet duct and an air intake from outside.
It is recommended that the position at the exhaustion duct exterior portion should be in
accordance with the data of the following figures and table:
Position of the exhaustion duct
A under a cornice
B between two horizontally-arranged ducts
C from a next window
D between two vertically-arranged ducts
E from a next venting grid
F under a balcony (*)
G under a window
H under a venting grid
I from a break back of a building
J from an angle of a building
K from the floor level
L from a vertically/horizontally-arranged outlet or pipe (**)
M from a front surface at a distance of 3 metres from the exhaust gas outlet
N like the previous one, but with opening
(*) In so far the balcony width does not exceed 2000 mm.
(**) If the pipe constructive materials were sensitive to the action from the flue gases, this distance
should be longer than 500 mm.
ATTENTION:
All the fittings used in the combustion products exhaustion and air intake are to
be those supplied by TRIANCO firm.
Minimum
distance
mm
300
1000
400
1500
600
300
600
600
300
300
2500
300
2000
3000
