- Page 1 TRIANCO OIL FIRED CENTRAL HEATING BOILERS FOR BALANCED OR CONVENTIONAL FLUE BED 92/42 EEC EMC 89/336 EEC USER, INSTALLATION COMMISSIONING & SERVICING INSTRUCTIONS EuroTrader 50/90 EuroTrader 100/125 To be retained by householder...
-
Page 2: Health And Safety
HEALTH AND SAFETY INFORMATION FOR THE INSTALLER AND SERVICE ENGINEERS Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is a requirement to provide information on substances hazardous to health (COSHH Regulations 1988). The Company takes every reasonable care to ensure that these products are designed and con- structed to meet these general safety requirements, when properly used and installed. - Page 3 CONTENTS PAGE USER INSTRUCTIONS After sales service information 1. INTRODUCTION 2. INSTALLATION Regulations Siting the Boiler Combustion Air Extractor fan Water System Electrical Supply Oil Supply 3. FLUE SYSTEM Conventional chimney Balanced flue (Room sealed) optional extra 2270 & 2271 Horizontal telescopic BF kit 9/10 Assembly Notes 2272 High level adaptor kit...
-
Page 4: User Instructions
60°C when the appliance is up to full operating temperature. The Trianco EuroTrader B/H has been designed and constructed to give years of trouble free service and The thermostat is switched off when the knob is turned these instructions are provided to assist you in obtaining fully anti-clockwise with pointer opposite ‘O’... -
Page 5: Simple Fault Finding
It is also worth noting that the heating system will Sludge and water caused by condensation should be usually remain effective for up to half an hour after drawn off at the tank drain-cock annually. boiler shut down. The timer can therefore be switched off earlier as an economy measure. -
Page 6: After Sales Service Information
The cause of a breakdown is due to other parts of the plumbing/heating system (including oil line/lack of What happens if my installer/engineer is oil), or with equipment not supplied by Trianco. unavailable? Step 3: Contact Trianco Direct. We will provide •... -
Page 7: Introduction
Trianco balanced flue kit. These kits allow the boiler to be diagonally opposite connections of the heat exchanger installed in a wide variety of site conditions, from low-level... -
Page 8: Installation
Sound Levels BS 5449: Part 1 - Forced Circulation Hot Water Systems. Whilst the low sound level of the Trianco EuroStar boiler BS 7074: Part 1 - Code of Practice for Sealed Water makes it eminently suitable for utility room installation, Systems. -
Page 9: Oil Supply
OIL SUPPLY The tank is less than 10m from a stream. The tank is less than 50m from a well, spring, or drinking water. The oil burner is factory set to burn 28 sec. Kerosene The tank cannot be viewed from the delivery point. to BS 2869. -
Page 10: Flue System
Oil De-aerator - b) Brick and masonry chimneys must be lined with a moisture and acid resistant liner of the same diameter Single pipe supply as boiler flue outlet. Where a two pipe suction lift system is required, but the The use of a flexible stainless steel liner is a convenient return pipe is too long, or impractical to run, an Oil De- method of lining brick and masonry chimneys. -
Page 11: Installation Notes
Whereas some balanced flue boilers rely on case sealing socket and all other joints. to achieve a room seal, Trianco boilers have a sealed air duct system which maintains the room sealed Fuel performance even when the casing door is removed for Only Kerosene 28 sec. - Page 12 Fig. 4...
- Page 13 7” 175mm MIN 18” 455mm 23” 585mm MIN 33” 850mm Fig. 5...
-
Page 14: Horizontal Telescopic Bf Kit
Trianco flue kits are designed to incorporate the latest ‘O’-ring seals. Before commencing assembly, please make sure that all ‘O’-rings seals are in position. 600mm HORIZONTAL TELESCOPIC BF KIT 1000mm HORIZONTAL TELESCOPIC BF KIT ASSEMBLY METHOD (Fig 4/5) ASSEMBLY METHOD (Fig 4/5) 1. - Page 15 Fig. 6...
-
Page 16: Horizontal Telescopic Bf Kit
Trianco flue kits are designed to incorporate the latest ‘O’-ring seals. Before commencing assembly, please make sure that all ‘O’-rings seals are in position. ASSEMBLY METHOD (Fig 6/7) - High Level Adaptor Kit used with 600mm Horizontal Telescopic BF Kit... -
Page 17: Universal High Level Bf Adaptor Kit
Item Description Part no. No. Off 600mm or 1000mm Horizontal Kit 2270 or 2271 Flue spigot terminal to outer 221716 No 6 Self tapping screws 91523 Outer flue pipe - Long 221725 Inner flue pipe - Short 221668 Outer pipe with hose connection 221662 Jubilee clip 95256... - Page 18 2273 VERTICAL BALANCED FLUE KIT FLAT ROOF PITCHED ROOF Fig. 8...
-
Page 19: Assembly Method
Vertical Balanced Flue Kit The vertical balanced flue kit is designed to be telescopic in nature and incorporates the latest ‘O’ring seals. It is therefore unnecessary for any ‘cutting down’ of pieces to the required size. Please note that to facilitate the connection process, each section of pipe has a different diameter. The lowermost pipes have the smallest diameter, the size increasing with each subsequent section of pipe. - Page 20 Item Description Part no. No. Off Apron Cravat 221674 Vertical terminal silencer 221672 Clamping strap 221673 M4 x 35 Pan head Pozi No. 8 Self tapping screw Silicone sponge 98112 Ceiling plate half 208583 Flue socket plate 207772 (supplied with boiler) Flue socket plate (WH70 only) 221648...
- Page 21 50/90 50/90 FIG 10 50/90 & 100/125 Oil Pipe Connections The burner is supplied for use with a one pipe oil sup- It is essential that for reliable operation and a condition ply system. If used on a two pipe system, it is necessary of the guarantee that an oil filter with a maximum mesh of 70ppm is fitted in the oil pipe from the tank to the to fit the by-pass plug in the oil pump.
-
Page 22: Electrical
4. ELECTRICAL Control Box Installation Electricity Supply 230V, Single Phase 50Hz All wiring to supply and all system components external to Insert thermostat phial into the top phial pocket on the the boiler must comply with the latest edition BS 7671 IEE L/H side of the boiler making sure not to trap the ther- Wiring Regulations. - Page 23 208871 6-OFF PART NO. EuroTrader 125 208838 BAFFLE ARRANGEMENT 3-OFF PART NO. 208834 1-OFF EuroTrader 50/90 BAFFLE ARRANGEMENT FLUE GAS SAMPLING POINT FLUE COVER BAFFLES MUST BE FITTED IN THE ARRANGEMENT SHOWN i.e. GAP ALTERNATING FROM BACK TO FRONT FIG. 12 BAFFLE DETAILS...
-
Page 24: Commissioning
(This applies to single pipe gravity system only). N.B. When used with a Trianco Balanced Flue it will be necessary to increase the air setting by 2 to 3 divisions Check that the time-switch (if fitted) is in the ON... -
Page 25: Servicing
6. SERVICING Servicing the Boiler (Burner removed) IMPORTANT: ISOLATE ELECTRICAL SUPPLY TO THE BOILER BEFORE SERVICING Remove flue-cover and lift out flue-baffles To maintain the boiler’s high thermal efficiency and (See Fig. 12). reliable operation, it should be serviced annually by a qualified engineer preferably OFTEC trained and Brush all deposits from flue-baffles and internal registered. -
Page 26: Fault Finding
7. FAULT FINDING ELECTRICITY SAFETY - Before making any electrical checks, switch off mains supply to boiler. FAULT POSSIBLE CAUSE ACTION BURNER WILL NOT START Control box locked out - Light on Press reset button on front of burner. N.B. ONLY TRY TWICE Boiler thermostat or other system Ensure all controls are calling for heat. -
Page 27: Fault Finding
FAULT FINDING (Cont’d) FAULT POSSIBLE CAUSE ACTION MORNING START LOCK-OUT Faulty non-return valve or air leak Replace non-return valve and cure leak. in two pipe system Low voltage Check with local Electricity Board. Combustion readings incorrect Check combustion under normal running conditions and compare readings with those given under ‘Burner Settings’. - Page 28 Fax: (0114) 257 1419 www.trianco.co.uk © Trianco Limited, Copyright in this brochure and the drawings or illustrations contained in it is vested in Trianco Limited and neither the brochure or any part thereof may be reproduced without prior written consent.
