Trianco TRO Evolution System Series Installation And Operating Instructions Manual page 44

Boiler
13
12
11
Pos. Code
1
SEPO000594
SEPO002235
2 CFER000059
3 CVAL000034
4 CFOV000148
5 CFER000051
6 MAIS000042
7
MAIS000041
8
CVAL000004
9
CFUR000022
10
SEPO001872
SEPO000691
SEPO000694
SEPO002255
SEPO002238
SEPO002245
10 SEPO001873
SEPO000689
SEPO000693
SEPO002254
10
9
Name
Door
Door W
Automatic door-close
Drainage valve
Heating circulating pump
Extraflex tube
Cast iron door's isolation
Cast iron fume cover
isolation
Safety valve with T.M.
Boiler colector
Left side 20 HFC
Left side 30 HFC
Left side 40 HFC
Left side 20 HFC W
Left side 30 HFC W
Left side 40 HFC W
Right side 20 HFC
Right side 30 HFC
Right side 40 HFC
Right side 20 HFC W
14
8 7 6 5 4 3
Pos. Code
SEPO002237
SEPO002244
11 SEPO000801
SEPO002240
12 SCON000803
13 SEPO000990
SEPO002252
14 SEPO001874
SEPO000690
SEPO000692
SEPO002253
SEPO002236
SEPO002243
15 CFER000048
16 CTOE000012
17 CFOV000025
CFOV000043
18 CFOV000024
19 CELC000252
20 SELEEVO020
SELEEVO025
15
16
17
19
18
20
2 1
Name
Right side 30 HFC W
Right side 40 HFC W
Side cover
Side cover W
Condenser
Rear panel
Rear panel W
Top cover 20 HFC
Top cover 30 HFC
Top cover40 HFC
Top cover 20 HFC W
Top cover 30 HFC W
Top cover40 HFC W
Click spring
Covers fixing clip
Expansion vessel 30 HFC
Expansion vessel 40 HFC
Automatic air vent
Pressure sensor
Electrical main board
Electrical main board W
page -44
