TRISTAR OPTIMA JUNIOR K CB AND SB WALL MOUNTED GAS BOILERS INSTALLATION INSTRUCTIONS TO BE RETAINED BY HOUSEHOLDER CB MODEL G.C. No: 47-897-06 SB MODEL G.C. No: 41-898-39...
INDEX: Warnings & Safety Advice page 5 Boiler Controls page 30 EEC Declaration of Conformity page 5 Starting the Boiler page 30 Contents of Pack page 5 Use of the Controls page 30 Standards & Regulations page 6 MODE Function - Adjustable page 31 Description of Appliance page 6...
Page 5
Failure to do so may invalidate the guarantee and jeopardise the safety of the boiler. Trianco is not held Please read these instructions carefully, as they liable for the malfunction of any of these components provide important directions for the safe installation, use and maintenance of the appliance.
Page 6
Do not mix different types of antifreeze. The addition of anything which may interfere with the Trianco cannot be held liable for damage caused to normal operation of the boiler without the written the boiler or water system as a result of the incorrect permission of Trianco Ltd could invalidate the use of antifreeze or other additives.
INSTALLATION AND ASSEMBLY The appliance must only be installed on sealed 3.2 UNIT ASSEMBLY heating systems. The boiler must be installed in a position complying Do not use galvanised radiators or pipework, as this with the dimensions set out in section 3.1. will lead to the formation of gas in the system.
Page 13
3.4 FILLING THE SYSTEM 3.5 CIRCULATING PUMP To fill the system once the pipework has been Before initial firing of the boiler, ensure that the pump connected, first gain access to the inside of the boiler has not become blocked by carrying out the following (see section 4, page 16) and open the cap on the operation: automatic air valve (item 23, page 10).
DIN 4726 and DIN 4729. the water line. Trianco is not liable for any damage caused to the 2) Into an external waste system, with the end of the appliance, system, or floor areas as a result of non- pipe into a gully below ground level, but above compliance with manufacturer’s instructions and the...
Page 15
3.11 PIPEWORK CONNECTION MANIFOLD The boiler is supplied with a pipework connection manifold (fig 12), simplifying the connection of the gas and water supplies. Mount the boiler as shown and described on the template provided and the manifold as shown on fig 11.
Page 16
ACCESS TO THE INSIDE OF THE BOILER To gain access to the combustion chamber, proceed as follows: 1) Remove the two screws from the underside of the control panel (fig 13) and bring forward, pulling from the top. 2) Remove the two screws behind the control panel. 3) Lift the front door upwards and then forward to remove.
ELECTRICAL Always isolate the power supply to the appliance before carrying out any work on the electrical systems and components. Wiring to the boiler must conform with all requirements of the current issue of the IEE Wiring Regulations for fixed wiring to a stationary appliance, and any local regulations which may apply.
Page 18
5.3 CONTROLS & WIRING Combi (CB) Model System (SB) Model The boiler should be connected to a double-channel The boiler should be connected to a double-channel programmer with volts-free switching to allow the programmer with volts-free switching to give the control of the central heating and hot water.
Only Trianco flues are permitted for use on this Please refer to the Trianco catalogue for a full list of appliance. Correct operation of other manufacturers’ available flues and configurations. flues on the boiler cannot be guaranteed.
Page 22
Extra that the flue assembly inclines slightly (2°) up wall clamping brackets are available from from the boiler to allow any condensation formed Trianco. Quote part code 510032. to run back to the appropriate drain.
Page 23
FIG. 27 6.4 HORIZONTAL BALANCED FLUE KIT (5010) Item Part No. Description 510021 Terminal 510023 90° Concentric Bend 510031 Clamp with Seal 510029 Ø60mm Seal (Black) 510027 Ø60mm Seal (Blue) 510028 Ø100mm Seal 510033 Wall Seal 510026 500mm Concentric Flue Pipe FIG.
Page 24
FIG. 30 6.7 90° CONCENTRIC BEND (5013) Item Part No. Description 510023 90° Concentric Bend 510027 Ø60mm Seal (Blue) 510028 Ø100mm Seal FIG. 31 6.8 45° CONCENTRIC BEND (5014) Item Part No. Description 510023 90° Concentric Bend 510027 Ø60mm Seal (Blue) 510028 Ø100mm Seal FIG.
Page 29
6.17 ALTERNATIVE FLUEING EXAMPLES When determining the flue length on non-typical flue courses, it is important to take into consideration that each additional elbow added to the run will dectract from the overall permitted flue length. A 90° elbow should be classed as reducing the length of the overall run by 1500mm. A 45°...
BOILER CONTROLS on/off switch boiler lock-out LED central heating temperature control boiler running LED DHW temperature control (combi only) ‘comfort’ function running LED master RESET button ‘comfort’ function on/off button MODE button multifunction display programming control (+) pressure gauge programming control (-) FIG.
7.3 MODE FUNCTION – ADJUSTABLE PARAMETERS The MODE function (button ‘E’) and the ‘+’ and ‘-‘ programming control buttons (‘F’ and ‘G’) are for use by the installation/commissioning engineer during the initial set-up of the boiler running parameters. To read or set these parameters, first press the reset button (‘D’), and while this is still held, press the MODE button (‘E’) for at least five seconds.
7.4 MODE FUNCTION – INFORMATION PARAMETERS To access the information-only parameters, press and hold the MODE button (‘E’) for 15 seconds. Repeatedly pressing the reset button will cycle through the available parameters to view. To exit from this function, press the MODE button once more, or leave the reset, ‘+’...
details of other fault codes and general fault-finding, 7.5 FROST THERMOSTAT refer to section 13. To prevent damage to the appliance during very cold 7.9 ANTILOCK FUNCTION weather, it is advisable to fit an external frost thermostat to the installation, which will supersede the central heating and hot water settings to temporarily After 21 hours of inactivity, the pump will activate for activate the boiler should the temperature drop too...
10 COMBUSTION ANALYSIS The combustion analysis should be carried out in heating mode. While in this function, the boiler temperature limits are deactivated and the boiler will operate at the maximum setting of 88°C. However, should this be problematic (e.g. in summer), it is possible to use the domestic hot water circuit If the values are found to be inconsistent with these, (combi model only).
Page 36
11 PROPANE CONVERSION To convert the boiler from natural gas operation to propane, the following steps must be carried out: 1) Isolate the electrical supply to the appliance. 2) Close the gas supply to the appliance. 3) Gain access to the internal sealed chamber of the appliance, following the directions on page 16.
12 SERVICING AND MAINTENANCE To ensure safe and efficient operation of the Clean the condensate trap by unscrewing the appliance, the boiler must be serviced at least once a plastic cover on the underside of the boiler. Check year by a CORGI-registered engineer. Failure to do so inside for deposits and clean as necessary.
12.2 BURNER & HEAT EXCHANGER SERVICING Ensuring that both the electrical supply and gas supply to the boiler are isolated, disconnect the gas pipe (item 1, fig 46). Remove the 2 x nuts (2) and remove the manifold (3). Disconnect the air pipe and electrical connections from the fan.
13 FAULT-FINDING After an appliance malfunction, the boiler will enter a lock-out state (indicated by the illumination of LED ‘H’). The multifunction display will show a three-digit fault code. In most cases, the fault can be eliminated by switching the boiler off then on, using ON/OFF button ‘A’.
If the problem persists, refer to the following fault-code chart: If in doubt, fully-trained Trianco technical operatives are available to help you with any on-site need. For technical advice, call 0114 257 2300 (Monday-Thursday: 08:30 – 16:45, Friday: 08:30 – 14:30).
14.1 CONTROLS CONNECTION PLUG On the System (SB) Model only, this item is used to connect external controllers to the boiler. See wiring diagram (section 5.6, fig 24) for correct placement. Using a crimping tool, attach the external control wiring to the terminals provided and insert into the plug provided. Connect as shown FIG.
