- Page 1 TRIANCO OIL FIRED CENTRAL HEATING BOILERS FOR BALANCED OR CONVENTIONAL FLUE BED 92/42 EEC EMC 89/336 EEC USER, INSTALLATION COMMISSIONING & SERVICING INSTRUCTIONS EUROSTAR 2000 50-65 70-90 To be retained by householder...
- Page 2 HEALTH AND SAFETY INFORMATION FOR THE INSTALLER AND SERVICE ENGINEERS Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is a requirement to provide information on substances hazardous to health (COSHH Regulations 1988). The Company takes every reasonable care to ensure that these products are designed and con- structed to meet these general safety requirements, when properly used and installed.
- Page 3 What happens if my installer/engineer is oil), or with equipment not supplied by Trianco. unavailable? Step 3: Contact Trianco Direct. We will provide you with • the name and telephone number of our Where the appliance falls outside the guarantee Service Agent.
-
Page 4: Table Of Contents
CONTENTS PAGE 1. USER INSTRUCTIONS After sales service information 2. INTRODUCTION 3. TECHNICAL INFORMATION Outline Dimensions Technical specifications 4. INSTALLATION Regulations Health and Safety Siting the Boiler Ventilation (Conventional flue boilers) Ventilation (room sealed balanced flue boilers) Extractor fan Heating and domestic hot water system Electrical supply Thermostats 5. -
Page 5: User Instructions
Temperature range of 82° C (high) to 55° C (low). The Trianco EuroStar has been designed and constructed to give years of trouble free service and Set the temperature by turning the knob to the required these instructions are provided to assist you in obtaining temperature. - Page 6 Sludge and water caused by condensation should be SYSTEMS CONTROLS drawn off at the tank drain-cock annually. ROOM THERMOSTAT SIMPLE FAULT FINDING The room thermostat should not be positioned near a If the burner fails to start for no apparent reason, make source of heat such as a radiator or exposed to the sun the following checks before calling your Service as this will cause the central heating to switch off before...
-
Page 7: After Sales Service Information
What happens if my installer/engineer is oil), or with equipment not supplied by Trianco. unavailable? Step 3: Contact Trianco Direct. We will provide you with • the name and telephone number of our Service Where the appliance falls outside the guarantee Agent. -
Page 8: Introduction
Trianco balanced flue kit. These kits allow the boiler to be installed in a wide variety of site conditions, from low-level Two flow and return sockets are provided to facilitate discharge through the wall, to high-level discharge (see connection to the heating and hot water systems. -
Page 9: Technical Information
3. TECHNICAL INFORMATION ALL DIMENSIONS IN MILLIMETRES MODEL FLUE SOCKET 50/65 FOR 4-5 in. DIAMETER FLUE 70/90 PIPE 1 in. BSP FLOW & RETURN SOCKETS (TWO EACH SIDE) EuroStar 50/65 70/90 117.5 OIL PIPE OR ELECTRIC CABLE ENTRY BOTH SIDES Fig. -
Page 10: Technical Specifications
- Adjustable up to and 82°C Limit Thermostat - Factory set at 110°C (hand reset) Casing Finish - Stove enamelled white with coloured facia trim Thermal Insulation - Boiler shell insulated with fibre glass Optional Extras - Trianco Balanced Flue Kits... - Page 11 CONTROL BOX WIRING HAND RESET MAINS LIMIT LIGHT LIGHT GREEN FIG. 2 WIRING DIAGRAM...
-
Page 12: Installation
550mm2 per kW of boiler rated output. The Control of Pollution (Oil) Regulations Current I.E.E. Regulations See Fig. 4 for air openings required for Trianco EuroStar Local Water Undertakings By-laws boilers: OFTEC Installation Requirements for Oil Fired Boilers and Oil Storage Tanks. -
Page 13: Ventilation (Room Sealed Balanced Flue Boilers)
If the boiler is to be installed on a gravity type system care Although no openings are required for the supply of must be taken, i.e. due to the high efficiency of the Trianco combustion air (this comes from outside through the air... -
Page 14: Oil Supply
5. OIL SUPPLY Pollution Protection To comply with building regulation section J6, the tank must be ‘bunded’ (i.e. double walled) if: The oil burner is factory set to burn 28 sec. Kerosene. The tank is less than 10m from a stream. Note: Only Kerosene is permitted for low level flue The tank is less than 50m from a well, spring, or drinking discharge. - Page 15 Oil De-aerator - Single pipe supply (Fig. 8) A none-return valve is not required with this system but the bypass plug must be fitted in the pump as for a two Where a two pipe suction lift system is required, but the pipe system.
- Page 16 • • FIG. 8 DE-AERATED OIL SUPPLY INSTALLATION...
-
Page 17: Flue System
To evacuate the products of combustion safely and thor- oughly, the boiler must have an efficient flue system. The Notes: design and construction of the Trianco Low Level (1) In view of the EuroStar’s high thermal efficiency, Discharger Kits already takes these factors into account... -
Page 18: Conventional Chimney
Whereas some balanced flue boilers rely on case sealing pressure, it is essential to seal all flue joints. to achieve a room seal, Trianco boilers have a sealed air Apply a thin bead of silicone sealant (supplied) duct system which maintains the room sealed... -
Page 19: 2270 & 2271 Horizontal Telescopic Bf Kit
Fig. 11... - Page 20 70/90 70/90 Fig. 12...
-
Page 21: Assembly Notes
Trianco flue kits are designed to incorporate the latest ‘O’-ring seals. Before commencing assembly, please make sure that all ‘O’-rings seals are in position. 600mm HORIZONTAL TELESCOPIC BF KIT 1000mm HORIZONTAL TELESCOPIC BF KIT ASSEMBLY METHOD (Fig 10/11) ASSEMBLY METHOD (Fig 10/11) 1. -
Page 22: 2270 High Level Adaptor Kit
Fig. 13... -
Page 23: Assembly Method
Trianco flue kits are designed to incorporate the latest ‘O’-ring seals. Before commencing assembly, please make sure that all ‘O’-rings seals are in position. ASSEMBLY METHOD (Fig 13/13a) - High Level Adaptor Kit used with 600mm Horizontal Telescopic BF Having decided the position of the boiler, cut a 170mm Slide the flue box through the cut out in the wall and square hole in the wall. -
Page 24: 2272 Universal Bf Kit
Item Description Part no. No. Off 600mm or 1000mm Horizontal Kit 2270 or 2271 Flue spigot terminal to outer 221716 No 6 Self tapping screws 91523 Outer flue pipe - Long 221725 Inner flue pipe - Short 221668 Outer pipe with hose connection 221662 Jubilee clip 95256... -
Page 26: Assembly Method
Vertical Balanced Flue Kit The vertical balanced flue kit is designed to be telescopic in nature and incorporates the latest ‘O’ring seals. It is therefore unnecessary for any ‘cutting down’ of pieces to the required size. Please note that to facilitate the connection process, each section of pipe has a different diameter. The lowermost pipes have the smallest diameter, the size increasing with each subsequent section of pipe. -
Page 27: 2273 Universal Bf Kit
Item Description Part no. No. Off Apron Cravat 221674 Vertical terminal silencer 221672 Clamping strap 221673 M4 x 35 Pan head Pozi No. 8 Self tapping screw Silicone sponge 98112 Ceiling plate half 208583 Flue socket plate 207772 (supplied with boiler) Flue socket plate (WH70 only) 221648... -
Page 28: Commissioning
7. COMMISSIONING 8. SERVICING IMPORTANT: ISOLATE ELECTRICAL SUPPLY TO THE It is strongly recommended that the boiler/burner unit is commissioned by a qualified technician, preferably BOILER BEFORE SERVICING OFTEC trained and registered. To maintain the boiler’s high thermal efficiency and It is the responsibility of the installer to ensure the boiler reliable operation, it should be serviced annually by a is properly commissioned, failure to do so will make the... -
Page 29: Burner
FLUE COVER PART NO. 208834 1 OFF EUROSTAR 90 EUROSTAR 65 BAFFLE ARRANGE- BAFFLE ARRANGE- MENT MENT BAFFLES MUST BE FITTED IN THE ARRANGEMENT SHOWN IE, GAP ALTERNAT- ING FROM BACK TO FIG 15 BAFFLE DETAILS FOR FRONT TRIANCO EUROSTAR 2000... -
Page 30: Fault Finding
9. FAULT FINDING ELECTRICITY SAFETY - Before making any electrical checks, switch off mains supply to boiler. FAULT POSSIBLE CAUSE ACTION BURNER WILL NOT START Control box locked out Press reset button on front of burner. (see separate burner leaflet) N.B. - Page 31 FAULT FINDING (Cont’d) FAULT POSSIBLE CAUSE ACTION POOR FLAME CUT-OFF Air in pump or at back of nozzle Bleed pump through pressure gauge port, also check for leaks in oil line if 2-pipe system. Oil contaminated with water Run off oil at burner until free of water and drain condensation from tank.
-
Page 32: Spares
10. SPARES 3 10 FIG. 16 EuroStar 2000 50/65 & 70/90 BOILER EXPLODED VIEW... -
Page 33: Boiler Parts
EuroStar Boiler Parts Item Description No. Off 50/65 70/90 Boiler Body 211229 211230 R/H Side Panel Assembly 221135 221135 L/H Side Panel Assembly 221134 221134 Top Panel Assembly 221137 221139 Back Panel 221143 221178 Boiler Control Thermostat 206896 206896 Limit Thermostat 206892 206892 Flue Socket Plate... - Page 34 Fax: (0114) 257 1419 www.trianco.co.uk © Trianco Limited, Copyright in this brochure and the drawings or illustrations contained in it is vested in Trianco Limited and neither the brochure or any part thereof may be reproduced without prior written consent.
