IWCi
UNITS' PERFORMANCE TABLE
MODEL
Speed
Total cooling output (1)
Sensitive cooling output (1)
Water flow rate (1)
Load loss (1)
Heating output (2)
Load loss (2)
Heating output (3)
Water flow rate (3)
Load loss (3)
Water content
Air flow rate
Absorbed power
Sound power (4)
Sound pressure (5)
Hydraulic connections
Unit dimensions H x W x D
Panel dimensions H x W x D
MODEL
Speed
Total cooling output (1)
Sensitive cooling output (1)
Water flow rate (1)
Load loss (1)
Heating output (2)
Load loss (2)
Heating output (3)
Water flow rate (3)
Load loss (3)
Water content
Air flow rate
Absorbed power
Sound power (4)
Sound pressure (5)
Hydraulic connections
Unit dimensions H x W x D
Panel dimensions H x W x D
1 Water temperature 7/12°C, D.B. air temperature 27°C, W.B. 19°C, 47%
humidity
2 Inlet water temperature 50°C, water flow rate during operation in cooling,
air temperature 20°C
3 Water temperature 70/60°C, air temperature 20°C
WC66000119 - Rev 01 È severamente vietata la riproduzione anche parziale di questo manuale / All copying, even partial, of this manual is strictly forbidden
Nominal technical characteristics for IWCi fan coils, models with 1 coil
32
1 2 3
kW 1,24 2,15 2,35
kW 0,91 1,78 2,00
l/h 212 368 404
kPa 3 8 9
kW 1,54 2,83 3,11
kPa 3 7 8
kW 2,64 4,87 5,35
l/h 232 427 469
kPa 3 9 10
dm3 0,43
m3/h 180 400 460
W 5 10 13
dB/A 30 41 44
dB/A 25 36 39
inches 1/2
mm 273 x 575 x 575
mm 64 x 730 x 730
Nominal technical characteristics for IWCi fan coils, models with 1 coil
62
1 2 3
kW 4,20 5,00 5,42
kW 3,14 3,70 3,99
l/h 721 859 930
kPa 16 22 25
kW 5,40 6,40 7,10
kPa 16 21 25
kW 9,2 10,9 12,1
l/h 808 956 1063
kPa 18 24 29
dm3 1,00
m3/h 850 1060 1160
W - 20 25
dB/A 43 48 49
dB/A 38 43 44
inches 3/4
mm 262 x 760 x 760
mm 78 x 860 x 860
42
4 1 2 3
2,60 1,70 3,50 4,00
2,23 1,16 2,63 3,05
445 292 600 686
11 3 11 14
3,49 1,87 4,35 4,85
10 3 10 13
6,00 3,14 7,38 8,20
527 275 648 719
12 2 11 13
0,86
520 200 530 630
15 8 24 28
46 32 48 51
41 27 43 46
1/2
273 x 575 x 575
64 x 730 x 730
82
4 1 2 3
6,00 5,50 6,50 8,00
4,40 4,11 5,08 6,10
1031 944 1116 1372
30 21 28 41
7,70 6,28 8,52 9,42
30 20 27 39
13,1 10,5 14,4 15,8
1150 920 1267 1385
33 18 31 37
1,50
1300 830 1090 1270
41 - 22 41
51 37 46 50
46 32 41 45
3/4
292 x 1050 x 760
78 x 1150 x 860
4 Sound power in compliance with ISO 3741 and ISO 3742
5 Sound pressure measured for a distance of 1 m, directionality factor of 4
52
4 1 2 3
4,60 2,47 3,80 4,42
3,56 1,84 2,97 3,51
788 423 653 758
17 7 14 18
5,70 3,35 5,33 6,14
17 6 14 18
9,65 5,74 9,15 10,5
847 504 803 924
18 8 19 24
0,86
750 370 630 760
36 12 34 40
55 41 53 57
50 36 48 52
1/2
273 x 575 x 575
64 x 730 x 730
102
4 1 2 3
9,10 6,24 8,09 8,90
6,84 4,69 6,17 6,87
1561 1069 1389 1529
51 27 42 50
10,2 7,34 9,53 10,6
48 26 42 49
17,0 12,3 16,0 17,8
1491 1079 1403 1561
42 25 40 48
1,50
1400 1200 1700 1980
55 - 36 43
53 43 49 53
48 38 44 48
3/4
292 x 1050 x 760
78 x 1150 x 860
4
5,06
4,04
869
23
6,75
23
11,5
1011
28
880
47
61
56
4
9,92
7,71
1702
60
11,7
60
19,6
1721
57
2300
64
57
52
7
